Dell WMGDP Workstation PC
Part Number:
WMGDP
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell WMGDP Workstation PC Overview
Dell Pro Max 14 Laptop
Experience performance and portability with the Dell Pro Max 14 laptop. Designed for power users, light design and creative applications in the office or on the go.
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core Ultra 7
Processor Model:
255H
Processor Core:
Hexadeca-core (16 Core)
Processor Threads:
16
Maximum Turbo Speed:
5.10 GHz
NPU Manufacturer:
Intel
NPU Name:
AI Boost
NPU Performance:
13 TOPS
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
16 GB
Maximum Supported System Memory:
64 GB
System Memory Technology:
LPDDR5X
System Memory Form Factor:
LPCAMM
Installed Slot Memory:
16 GB
Installed Slot Memory Configuration:
1 x 16GB
Total Number of Memory Slots:
1
Number of Occupied Memory Slots:
1
Number of Free Memory Slots:
0
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
SSD Form Factor:
M.2
Display & Graphics
Screen Size:
14"
Display Screen Type:
LCD
Standard Refresh Rate:
60 Hz
Screen Mode:
Full HD Plus
Screen Resolution:
1920 x 1200
Brightness:
300 Nit
Color Gamut:
45% NTSC
Touchscreen:
No
Graphics Controller Manufacturer:
Intel
Graphics Controller Model:
Arc Pro 140T Graphics
Graphics Memory Technology:
LPDDR5X
Graphics Memory Accessibility:
Shared
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11be
Ethernet Technology:
Gigabit Ethernet
Bluetooth:
Yes
Built-in Devices
Front Camera/Webcam:
Yes
Infrared Camera:
Yes
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
2
Number of USB 3.2 Gen 1 Type-A Ports:
2
Network (RJ-45):
Yes
Number of Thunderbolt 4 Ports:
2
Optional Ports:
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 x Smart-card reader slot (optional)
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Input Devices
Keyboard Backlight:
Yes
Keyboard Localization:
English (US)
Copilot Key:
Yes
Battery Information
Number of Cells:
4-cell
Power Description
Power Plug Type:
Type C
Included Charger Power:
100 W
USB Power Delivery Support:
Yes
Physical Characteristics
Height:
0.97"
Width:
12.3"
Depth:
8.9"
Weight (Approximate):
4.03 lb
Miscellaneous
Package Contents:
- Pro Max 14 MC14250
- Lithium Polymer Battery
- AC Adapter
- Power Cord
- Documentation
- Quick Setup Guide
Systems Management:
Intel vPro Technology Disabled
Charger Included:
Yes
Features:
- ExpressCharge
- Anti-glare Screen
Energy Star:
Yes
Country of Origin:
Vietnam
TCO Certified:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116490609
UPC:
884116490609
EAN:
0884116490609
UNSPSC:
43211503
Frequently Asked Questions
What are the display specifications for the Dell WMGDP Workstation PC?
The Dell WMGDP features a 14.0" HD display with 1366x768 resolution and wide-view outdoor viewable LED technology. The screen comes with impact-resistant protective front glass and is available in both standard and resistive touchscreen options to suit different workflow requirements.
What graphics options are available on this Dell workstation?
The Dell WMGDP offers multiple graphics configurations including Intel HD Graphics 4000 (for Intel Core i3/i5/i7 3xxxM processors), Intel HD Graphics 3000 (for Intel Core i3 processors), and NVIDIA NVS 5200M discrete graphics with Optimus technology. The discrete GPU option provides 1GB of GDDR5 memory for enhanced performance in demanding applications.
What storage options does the Dell WMGDP support?
This workstation supports multiple storage configurations including 7200 rpm SATA drives up to 750GB, 5400 rpm SATA drives up to 320GB, and solid-state options up to 256GB with optional encryption (FDE/SED FIPS Opal). The system also features Dell Fast Response Free Fall Sensor and HDD Isolation as standard, plus an optional E-Module Bay II for secondary storage expansion.
What connectivity and ports does the Dell WMGDP provide?
The Dell WMGDP includes USB/eSATA combo ports, HDMI, SmartCard reader, network RJ-45 connector, serial DB9 pin, and stereo headphone/microphone combo jack. Optional connectivity upgrades include USB 3.0 ports via media bay module and a contactless SmartCard reader for enhanced security and flexibility.
Is the Dell WMGDP suitable for field work and rugged environments?
Yes, the Dell WMGDP is designed for mobile professionals with features like impact-resistant protective front glass, optional rugged battery slice, removable LCD protective touch overlay, and cable lock slots for physical security. The system weighs starting at 8.8 lbs with a 6-cell battery, making it portable for on-site work while maintaining durability standards.
What security features does this Dell workstation offer?
The Dell WMGDP includes comprehensive security with Smart Card Reader, optional fingerprint reader, ControlVault technology, TPM 1.2, and optional contactless Smart Card Reader support. Additional physical security features include battery and hard drive locks, plus optional Intel vPro Technology for advanced management capabilities when paired with Intel WiFi Link WLAN.
