Dell VXN4R Server

Part Number: VXN4R
Model: Parts
Add to My Shopping List Add to Compare
$26,276.03
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
2
Number of Processors Installed
1
Processor Type
Xeon Gold
Processor Model
5412U

Product Description:

  Dell PowerEdge R660xs 1U Rack-mountable Server - 1 Xeon Gold 5412U 2.10 GHz - 32 GB RAM - 480 GB SSD - Intel Chip - 2 Processor Support - 1.50 TB RAM Support - DDR5 SDRAM - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - 2 x 800 W - Redundant Power Supply
Explore all Dell Misc Parts ACCESSORIES & MISC. ITEMs
Add to Quote
Dell VXN4R Server
Dell VXN4R Server
Dell VXN4R Server
Dell VXN4R Server
Dell VXN4R Server
Dell VXN4R Server
Dell VXN4R Server Dell VXN4R Server Dell VXN4R Server Dell VXN4R Server Dell VXN4R Server Dell VXN4R Server

Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview

Products and parts from Dell.
Dell VXN4R Server Overview

Best choice in balanced and dense compute for the most popular IT applications | Buy the performance and density you need

The new Dell PowerEdge R660xs is a 1U, two-socket rack server. Buy the best fit in dense performance with this purpose-built 1U system. Focused on delivering the latest technology to power the most popular applications and workloads used by businesses today, including virtualization, scale out-database and high performance compute. All delivered in a thoughtfully crafted platform that will provide dense compute that fits in your current infrastructure.

Easily configurable

  • Add up to two 5th generation Intel® Xeon® Scalable processors with up to 28 cores and 4th generation Intel® Xeon® Scalable processors with up to 32 cores per socket for faster performance
  • Accelerate in-memory workloads with up to 16 DDR5 RDIMMS up to 5200 MT/sec
  • Improve data throughput and reduce latency with support up to 5 I/O devices (up to 3 PCIe slots, 1 OCP 3.0 networking slot, and 1 dedicated PERC slot)
  • Storage options include up to 4x 3.5" HDDs/SSDs; or up to 10x 2.5" HDDs/SSDs/NVMe

A breeze to cool

  • Thoughtfully designed to fit in your current air-cooled infrastructure
  • Alleviate the worry about expensive liquid cooling retrofitting to your data center
  • Sychronize your workload needs with a tailored performance configuration that is air-cooled
  • Minimize the carbon footprint of your data center by better matching the system power consumption with anticipated workload requirements

Cyber Resilient Architecture for Zero Trust IT environment & operations

Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations.

Increase efficiency and accelerate operations with autonomous collaboration

The Dell OpenManage™ systems management portfolio delivers a secure, efficient, and comprehensive solution for PowerEdge servers. Simplify, automate and centralize one-to-many management with the OpenManage Enterprise console and iDRAC.

Sustainability

From recycled materials in our products and packaging, to thoughtful, innovative options for energy efficiency, the PowerEdge portfolio is designed to make, deliver, and recycle products to help reduce the carbon footprint and lower your operation costs. We even make it easy to retire legacy systems responsibly with Dell Technologies Services.

Rest easier with Dell Technologies Services

Maximize your PowerEdge Servers with comprehensive services ranging from Consulting, to ProDeploy and ProSupport suites, Data Migration and more - available across 170 locations and backed by our 60K+employees and partners.

Processor
Number of Processors Supported:
2
Number of Processors Installed:
1
Processor Type:
Xeon Gold
Processor Model:
5412U
Processor Core:
Tetracosa-core (24 Core)
Processor Speed:
2.10 GHz
Cache:
45 MB
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
32 GB
Maximum Memory Supported:
1.50 TB
Memory Technology:
DDR5 SDRAM
Error Checking:
ECC
Number of Occupied Memory Slots:
2
Signal Processing:
Registered (Buffered)
Storage
Total Solid State Drive Capacity:
480 GB
Solid State Drive Interface:
Serial ATA/600
Controllers
Controller Model:
Front PERC H755 Front Load
I/O Expansions
Number of Total Expansion Bays:
8
Number of Internal 2.5" Bays:
8
Number of SFF Bays:
8
PCI Express Details:
1 CPU Configuration: Up to 2 PCIe slots (1 x16 Gen4 + 1 x8 Gen5); 2 CPU configuration: Up to 3 PCIe Gen4 slots (1 x16 Gen4 + 2 x8 Gen4) or up to 2 PCIe Gen5 slots (1 x16 Gen5 + 1 x8 Gen5)
Riser Card:
Riser Config 3, Low Profile, 1x16 LP Slots (Gen4)
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports:
3
Number of USB 2.0 Ports:
2
Number of USB 3.0 Ports:
1
Network (RJ-45):
Yes
VGA:
Yes
Number of VGA Ports:
2
Remote Management:
Yes
Remote Management Controller:
iDRAC9, Datacenter 16G
Operating System
Operating System Supported:
  • Ubuntu Server
  • Hyper-V
  • Windows Server
  • Red Hat Enterprise Linux
  • SuSE Linux Enterprise Server
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Installed:
2
Plug/Connector Type:
NEMA 5-15P to C13
Maximum Power Supply Wattage:
800 W
Redundant Power Supply:
Yes
Hot Swappable Power Supply:
Yes
Power Source:
Power Supply
Physical Characteristics
Form Factor:
Rack-mountable
Rack Height:
1U
Height:
1.7"
Width:
19"
Depth:
29.5"
Weight (Approximate):
42.88 lb
Miscellaneous
Package Contents:
  • PowerEdge R660xs Server
  • 2 X NEMA 5-15P to C13 Wall Plug, 125 Volt, 15 AMP, 10 Feet (3m), Power Cord, North America
  • ReadyRails A11 drop-in/stab-in Slide Combo Rails Without Cable Management Arm
  • PowerEdge R660xs, 8x2.5, Short Drive Shipping Material
Security Features:
  • Cryptographically signed firmware
  • Data at Rest Encryption (SEDs with local or external key mgmt)
  • Secure Boot
  • Secure Erase
  • Secured Component Verification (Hardware integrity check)
  • Silicon Root of Trust
  • System Lockdown (requires iDRAC9 Enterprise or Datacenter)
  • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Warranty
Limited Warranty:
40 Month
Additional Warranty Information:
  • Next Bus. Day 39MO(Disti SNS), 39 Month(s)
  • Next Bus. Day (Disti SNS), 40 Month(s)
Item Numbers
GTIN: 0884116461623
UPC: 884116461623
EAN: 0884116461623
UNSPSC: 43211501

Frequently Asked Questions

The Dell PowerEdge R660xs is a 1U rack-mountable server featuring a single Xeon Gold 5412U processor running at 2.10 GHz with support for up to 2 processors and 1.50 TB of RAM. It comes standard with 32 GB of DDR5 SDRAM, 480 GB SSD storage, and includes 8 small form factor (SFF) bays for expansion. The server is equipped with dual 800W redundant power supplies and Gigabit Ethernet connectivity for reliable enterprise operations.

Yes, the Dell PowerEdge R660xs is well-suited for warehouse and logistics environments requiring reliable server infrastructure. Its redundant power supply design ensures high availability, while the 8 SFF storage bays provide flexible capacity for database and inventory management systems. We offer this server as part of our comprehensive AIDC solutions for logistics operations—contact us today to discuss your specific warehouse requirements.

The Dell PowerEdge R660xs supports DDR5 SDRAM with a maximum capacity of 1.50 TB, providing ample memory for demanding applications. Storage-wise, the server features 8 small form factor (SFF) bays that can accommodate various SSD and HDD configurations beyond the standard 480 GB SSD, allowing you to scale storage capacity based on your operational needs.

The Dell PowerEdge R660xs includes Gigabit Ethernet connectivity for fast, reliable network communications essential in warehouse and logistics environments. This networking capability supports seamless integration with barcode scanners, mobile computers, and other AIDC devices we offer for complete supply chain visibility and management.

The Dell PowerEdge R660xs supports up to 2 processors, with the base configuration featuring a single Xeon Gold 5412U processor at 2.10 GHz. This dual-processor support capability allows for increased computational power and performance scaling as your warehouse or logistics operations grow.

The Dell PowerEdge R660xs delivers enterprise-grade reliability through its redundant 800W power supplies, DDR5 memory technology, and robust 1U form factor designed for data center deployment. The combination of Intel Xeon Gold processors, extensive storage expansion options, and Gigabit Ethernet ensures consistent uptime for mission-critical warehouse management and logistics applications. Visit barcodesinc.com to learn how this server integrates with our complete AIDC ecosystem.
