Release Year:
2023
Dell T2M08 Workstation PC
Part Number:
T2M08
Model:
Parts
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core i7
Processor Generation:
13th Gen
Processor Model:
i7-13850HX
Processor Core:
Icosa-core (20 Core)
Processor Threads:
28
Processor Speed:
2.20 GHz
Maximum Turbo Speed:
5.30 GHz
vPro Technology:
Yes
Chipset
Chipset Manufacturer:
Intel
Memory
Total Installed System Memory:
32 GB
Maximum Supported System Memory:
128 GB
System Memory Technology:
DDR5 SDRAM
System Memory Speed:
4800 MHz
System Memory Form Factor:
CAMM
Installed Slot Memory:
32 GB
Installed Slot Memory Configuration:
1 x 32GB
Total Number of Memory Slots:
1
Number of Occupied Memory Slots:
1
Number of Free Memory Slots:
0
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
1 TB
SSD Form Factor:
M.2
Display & Graphics
Screen Size:
17.3"
Display Screen Technology:
ComfortView Plus
Standard Refresh Rate:
60 Hz
Screen Mode:
Full HD
Screen Resolution:
1920 x 1080
Brightness:
500 Nit
Color Gamut:
99% DCI-P3
Touchscreen:
No
Graphics Controller Manufacturer:
NVIDIA
Graphics Controller Model:
RTX 3500 Ada
Graphics Memory Capacity:
12 GB
Graphics Memory Technology:
GDDR6
Graphics Memory Accessibility:
Dedicated
VR Ready:
Yes
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11ax
Wimax:
No
Ethernet Technology:
Gigabit Ethernet
Bluetooth:
Yes
WWAN Supported:
No
Near Field Communication:
No
Built-in Devices
Camera Privacy Shutter:
Yes
Front Camera/Webcam:
Yes
Infrared Camera:
Yes
Finger Print Reader:
No
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
3
Number of USB 3.2 Gen 1 Type-A Ports:
2
Number of USB 3.2 Gen 2 Type-C Ports:
1
Network (RJ-45):
Yes
Number of Thunderbolt 4 Ports:
2
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Input Devices
Keyboard Backlight:
Yes
Keyboard Localization:
English (US)
Battery Information
Number of Cells:
6-cell
Power Description
Maximum Power Supply Wattage:
240 W
Physical Characteristics
Color Family:
Gray
Product Color:
Aluminum Titan Gray
Height:
1.12"
Width:
15.7"
Depth:
10.4"
Weight (Approximate):
6.72 lb
Miscellaneous
Package Contents:
- Mobile Precision 7780
- Lithium Ion Battery
- AC Adapter
- Quick Setup Guide for Mobile Precision 7780
- Safety and Regulatory Documents English,French,Dutch
- E5 Power cord
Charger Included:
Yes
Features:
- Anti-glare Screen
- ExpressCharge
Energy Star:
Yes
Country of Origin:
China
TCO Certified:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
- Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
- TCO Certified Edge
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116455004
UPC:
884116455004
EAN:
0884116455004
UNSPSC:
43211503
Frequently Asked Questions
What are the key specifications of the Dell T2M08 Precision 7780 workstation?
The Dell Precision 7780 features a 13th Gen Intel Core i7-13850HX processor with 20 cores, 32 GB of RAM, 1 TB SSD storage, and a 17.3" Full HD display (1920 x 1080). It includes an NVIDIA RTX 3500 Ada graphics card with 12 GB of dedicated VRAM, making it ideal for demanding design, engineering, and content creation workloads. The system runs Windows 11 Pro and includes IEEE 802.11ax wireless connectivity for enterprise environments.
Is the Dell Precision 7780 suitable for CAD and 3D rendering work?
Yes, the Dell Precision 7780 is purpose-built for professional CAD, 3D modeling, and rendering applications. The combination of the 20-core Intel Core i7-13850HX processor and NVIDIA RTX 3500 Ada graphics with 12 GB VRAM provides the computational power needed for complex design work, real-time visualization, and high-performance rendering tasks. This workstation is certified for professional applications from Autodesk, Dassault Systèmes, and other leading design software vendors.
What connectivity options does the Dell T2M08 offer?
The Dell Precision 7780 includes IEEE 802.11ax (Wi-Fi 6) wireless connectivity for fast, reliable network access in modern office environments. It features multiple USB ports, HDMI output, and Ethernet connectivity for peripheral and network connections. The system also includes a front-facing camera/webcam for video conferencing and collaboration. Contact us today to confirm specific port configurations for your configuration.
Can the Dell Precision 7780 be upgraded or customized?
Yes, the Dell Precision 7780 offers configurable options to meet specific business requirements. Memory, storage, and graphics configurations can be tailored during purchase to match your workload demands. We offer multiple SKU configurations available from us, including options with different processors, RAM, and storage capacities. Visit barcodesinc.com or contact us today to discuss custom configuration options for your team.
What operating system and software does the Dell Precision 7780 come with?
The Dell Precision 7780 ships with Windows 11 Pro, providing enterprise-grade security, management features, and compatibility with professional software applications. Windows 11 Pro includes remote desktop capabilities, advanced encryption, and system management tools ideal for IT-managed environments in warehouses and logistics operations. The system supports ComfortView Plus technology to reduce eye strain during extended work sessions.
How does the Dell Precision 7780 compare to previous generation workstations?
The Dell Precision 7780 represents a significant performance upgrade with its 13th Gen Intel Core i7-13850HX processor (20 cores) compared to older 8th and 9th generation systems, delivering substantially faster computation for complex tasks. The NVIDIA RTX 3500 Ada graphics architecture provides improved ray tracing and AI-accelerated rendering capabilities for modern design workflows. The 17.3" display and 32 GB RAM configuration also provide more screen real estate and memory headroom than many legacy workstations. Contact us today to compare specifications with your current systems.
