Release Year:
2024
Dell PX86J Desktop PC
Part Number:
PX86J
Model:
Parts
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core i7
Processor Generation:
14th Gen
Processor Model:
i7-14700
Processor Core:
Icosa-core (20 Core)
Processor Threads:
28
Processor Speed:
2.10 GHz
Maximum Turbo Speed:
5.30 GHz
vPro Technology:
Yes
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
16 GB
Maximum Memory Supported:
128 GB
Memory Technology:
DDR5 SDRAM
Memory Configuration:
2 x 8GB
Total Number of Memory Slots:
4
Number of Occupied Memory Slots:
2
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
Solid State Drive Interface:
PCI Express NVMe 4.0
SSD Form Factor:
M.2
Optical Drive Type:
DVD-Writer
Optical Media Supported:
DVD±R/±RW
Display & Graphics
Graphics Controller Manufacturer:
Intel
Graphics Controller Model:
UHD Graphics 770
Graphics Memory Technology:
DDR5 SDRAM
Graphics Memory Accessibility:
Shared
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Wireless LAN:
No
Bluetooth:
No
Input Devices
Keyboard Localization:
English (US)
Interfaces/Ports
Number of HDMI Outputs (Rear):
1
HDMI (Rear):
Yes
Total Number of USB Ports:
10
Number of USB 2.0 Ports (Front):
2
Number of USB 2.0 Ports (Rear):
2
Number of USB 3.2 Gen 1 Ports:
3
Number of USB 3.2 Gen 2 Ports:
2
Number of USB 3.2 Gen 2x2 Type-C Ports:
1
Number Of Ethernet Ports:
1
Number of DisplayPort Outputs (Rear):
3
DisplayPort (Rear):
Yes
Optional Ports:
1 Video Port (HDMI 2.1/DisplayPort™ 1.4a/VGA/USB Type-C with DisplayPort™ Alt mode) (optional) 1 Serial Port (optional)
Details regarding optional ports aggregated from the information available for this product's family/series
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Power Description
Maximum Power Supply Wattage:
260 W
Physical Characteristics
Color Family:
Black
Product Color:
Black
Form Factor:
Small Form Factor
Height:
11.4"
Width:
3.7"
Depth:
11.5"
Weight (Approximate):
12.39 lb
Miscellaneous
Package Contents:
- OptiPlex Small Form Factor (Plus 7020)
- Wireless Keyboard
- Wireless Mouse
- USB Receiver
- Power Cord
- Quick Start Guide
- Safety/Environment and Regulatory Guide (English/French Multi-language)
Features:
Security Slot
Energy Star:
Yes
Country of Origin:
Mexico
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
Energy Efficiency Certification:
ENERGY STAR 8.0
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116462286
UPC:
884116462286
EAN:
0884116462286
UNSPSC:
43211507
