Release Year:
2025
Dell KCMNM Desktop PC
Part Number:
KCMNM
Model:
Parts
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core i5
Processor Generation:
14th Gen
Processor Model:
i5-14500T
Processor Core:
Tetradeca-core (14 Core)
Processor Threads:
20
Processor Speed:
1.70 GHz
Maximum Turbo Speed:
4.80 GHz
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
8 GB
Maximum Memory Supported:
64 GB
Memory Technology:
DDR5 SDRAM
Memory Configuration:
1 x 8GB
Number of Occupied Memory Slots:
1
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
256 GB
Solid State Drive Interface:
PCI Express NVMe 4.0
SSD Form Factor:
M.2
Display & Graphics
Graphics Controller Manufacturer:
Intel
Graphics Controller Model:
UHD Graphics 770
Graphics Memory Technology:
DDR5 SDRAM
Graphics Memory Accessibility:
Shared
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11ax
Bluetooth:
Yes
Input Devices
Keyboard Localization:
English (US)
Interfaces/Ports
Number of HDMI Outputs:
1
HDMI (Rear):
Yes
Total Number of USB Ports:
6
Number of USB 2.0 Ports (Rear):
2
Number of USB 3.2 Gen 1 Ports:
3
USB Type-C (Front):
Yes
USB Type-C Detail:
1 USB 3.2 Gen 2 (10 Gbps) Type-C® port
Number Of Ethernet Ports:
1
Number of DisplayPort Outputs (Rear):
1
DisplayPort (Rear):
Yes
Optional Ports:
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 Optional Module Port (HDMI 2.1 TMDS/DisplayPort™1.4a (HBR3)/VGA/USB Type-C®with DisplayPort™Alt Mode/2 USB-A 3.2 Gen 2/PS2 and Serial/Serial Module/5G Optical Fiber)
- Optional USB Type-C with DisplayPort Alt mode with Power In Cable
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Power Description
Maximum Power Supply Wattage:
90 W
Physical Characteristics
Color Family:
Black
Product Color:
Black
Form Factor:
Micro PC
Height:
7.2"
Width:
1.4"
Depth:
7"
Weight (Approximate):
3.09 lb
Miscellaneous
Package Contents:
- Pro Micro QCM1250
- Keyboard
- Mouse
- Quick Start Guide
- Documentation
- AC Adapter
- Power Cord
Systems Management:
No vPro Support
Features:
Security Slot
Energy Star:
Yes
Country of Origin:
Mexico
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116488286
UPC:
884116488286
EAN:
0884116488286
UNSPSC:
43211507
Frequently Asked Questions
What processor does the Dell KCMNM Desktop PC use?
The Dell KCMNM features an Intel Core i5 14500T vPro processor with 14 cores and speeds up to 4.8GHz, designed for professional workloads. This 35W processor is built into Dell's Pro Micro compact form factor, making it ideal for space-constrained warehouse and logistics environments where computing power meets efficiency.
How much storage and memory does this Dell desktop come with?
The Dell KCMNM includes 8GB of DDR5 SDRAM (1 x 8GB module) with speeds up to 4800 MT/s, plus a 256GB SSD with TLC technology for fast boot and application performance. This configuration balances responsiveness for typical warehouse management and inventory applications with reliable solid-state storage.
Is the Dell KCMNM suitable for warehouse management systems?
Yes, the Dell KCMNM is well-suited for warehouse and logistics operations, featuring Windows 11 Pro with vPro technology for secure remote management and hardware-only support. The Pro Micro compact design saves valuable desk space in warehouse offices while delivering the processing power needed for inventory, barcode scanning, and logistics software.
What warranty and support does the Dell KCMNM include?
The Dell KCMNM comes with a 3-year Basic Onsite Service agreement that includes hardware-only support after remote diagnosis, ensuring minimal downtime in your warehouse operations. We offer this desktop with comprehensive support options available from us to keep your logistics infrastructure running smoothly.
What are the power requirements for the Dell KCMNM Desktop PC?
The Dell KCMNM operates with a 180W external power adapter, delivering efficient power management for the 35W processor and supporting components. This power specification makes it suitable for standard office and warehouse environments without requiring specialized electrical infrastructure.
Does the Dell KCMNM support remote management for IT procurement teams?
Yes, the Dell KCMNM includes Intel vPro technology, which enables advanced remote management capabilities essential for IT teams overseeing multiple warehouse locations. This feature allows for secure remote diagnostics, updates, and hardware monitoring without requiring on-site intervention, reducing IT support costs across your distribution network.
The Dell KCMNM Desktop PC is also known as
VEL-KCMNM
