Dell J8Y8M Desktop PC
Part Number:
J8Y8M
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell J8Y8M Desktop PC Overview
Dell Pro Max Micro Desktop
Engineered for those who demand exceptional power without sacrificing space, the Dell Pro Max Micro delivers top-tier speed and efficiency in a sleek, space-saving design.
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core Ultra 7
Processor Model:
265
Processor Core:
Icosa-core (20 Core)
Processor Threads:
20
Processor Speed:
2.40 GHz
Maximum Turbo Speed:
5.30 GHz
vPro Technology:
Yes
NPU Manufacturer:
Intel
NPU Name:
AI Boost
NPU Performance:
13 TOPS
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
16 GB
Maximum Memory Supported:
64 GB
Memory Technology:
DDR5 SDRAM
Memory Configuration:
1 x 16GB
Number of Occupied Memory Slots:
1
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
Solid State Drive Interface:
PCI Express NVMe 4.0
SSD Form Factor:
M.2
Display & Graphics
Graphics Controller Manufacturer:
NVIDIA
Graphics Controller Model:
RTX A1000
Graphics Memory Capacity:
Up to 8 GB
Graphics Memory Technology:
GDDR6
Graphics Memory Accessibility:
Dedicated
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11be
Bluetooth:
Yes
Input Devices
Keyboard Localization:
English (US)
Interfaces/Ports
Total Number of USB Ports:
8
Number of USB 3.2 Gen 1 Ports:
2
Number of USB 3.2 Gen 2 Ports:
4
Number of USB 3.2 Gen 2x2 Type-C Ports:
1
USB Type-C (Rear):
Yes
USB Type-C Detail:
1 USB 3.2 Gen 2 (10 Gbps) Type-C® port;
Number Of Ethernet Ports:
1
Number of DisplayPort Outputs (Rear):
3
DisplayPort (Rear):
Yes
Mini DisplayPorts Quantity:
4
Optional Ports:
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 optional module port (VGA/HDMI 2.1 FRL/DisplayPort™ 2.1 (UHBR20)/Serial/PS2/USB Type C®with DisplayPort™ Alt Mode/2 USB Type-A/Thunderbolt 4 + USB Type-C®/5G Optical Fiber/5GbE LAN NIC)
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Power Description
Maximum Power Supply Wattage:
280 W
Physical Characteristics
Color Family:
Black
Product Color:
Black
Form Factor:
Micro PC
Height:
8.1"
Width:
3.1"
Depth:
7"
Weight (Approximate):
5.60 lb
Miscellaneous
Package Contents:
- Pro Max Fcm2250 Desktop Computer
- Mouse
- Keyboard
- US Power Cord
- AC Adapter
- 4 x mDP to DP Adapters
- Quick Setup Guide
Systems Management:
Intel vPro Active Management Tech
Features:
Security Slot
Energy Star:
Yes
Country of Origin:
Mexico
TCO Certified:
Yes
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116487975
UPC:
884116487975
EAN:
0884116487975
UNSPSC:
43211507
Frequently Asked Questions
What processor and vPro capabilities does the Dell J8Y8M desktop offer?
The Dell J8Y8M features an Intel Core Ultra 7 265 processor with vPro Technology, which provides advanced management capabilities ideal for enterprise environments. This combination enables remote management, security features, and system control—making it well-suited for warehouse and logistics operations that require IT oversight across multiple workstations.
Is the Dell J8Y8M suitable for graphics-intensive warehouse management applications?
Yes, the Dell J8Y8M includes an NVIDIA RTX A1000 with 8 GB GDDR6 dedicated graphics memory, making it capable of handling graphics-intensive applications. This discrete GPU is ideal for running complex warehouse management software, inventory visualization tools, and real-time logistics dashboards without relying on integrated graphics.
What storage and memory configuration does the Dell J8Y8M provide?
The Dell J8Y8M comes standard with 16 GB of RAM and a 512 GB SSD, providing fast boot times and responsive application performance for warehouse management systems. The SSD storage ensures quick data access for logistics software and reduces system latency during peak operational hours.
What connectivity options are available on the Dell J8Y8M?
The Dell J8Y8M includes IEEE 802.11be wireless LAN for high-speed network connectivity, along with standard wired network capabilities. These connectivity options ensure reliable communication with warehouse systems, barcode scanners, mobile computers, and other AIDC devices available from us at Barcodes Inc.
What operating system and security features does the Dell J8Y8M include?
The Dell J8Y8M ships with Windows 11 Pro, which provides enterprise-grade security and management features suitable for warehouse environments. Combined with Intel vPro Technology, it supports advanced security protocols and remote management capabilities essential for protecting sensitive logistics and inventory data.
Is the Dell J8Y8M a compact form factor suitable for space-constrained warehouse offices?
Yes, the Dell J8Y8M is a Micro PC desktop form factor, making it an excellent choice for warehouse offices, control rooms, or logistics centers with limited desk space. Its compact design doesn't compromise on performance, allowing you to maximize workspace while maintaining full desktop computing power for inventory management and AIDC system integration. Contact us today at barcodesinc.com to discuss how this system integrates with your warehouse technology stack.
