Dell DELL-E2225HSM Touchscreen

Part Number: DELL-E2225HSM
Model: Parts
Add to My Shopping List Add to Compare
$177.82
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Screens
1
Screen Size Class
22"
Viewable Screen Size
21.5"
Screen Mode
Full HD

Product Description:

  Dell Pro E2225HSM 22" Class Full HD LED Monitor - 16:9 - 21.5" Viewable - Vertical Alignment (VA) - LED Edgelight System Backlight - 1920 x 1080 - 16.7 Million Colors - 250 Nit - 5 ms - 100 Hz Refresh Rate - Speakers - HDMI - VGA - DisplayPort - VESA Mount Compatible
Explore all Dell Misc Parts ACCESSORIES & MISC. ITEMs
Add to Quote
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen
Dell DELL-E2225HSM Touchscreen Dell DELL-E2225HSM Touchscreen Dell DELL-E2225HSM Touchscreen Dell DELL-E2225HSM Touchscreen Dell DELL-E2225HSM Touchscreen Dell DELL-E2225HSM Touchscreen

Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview

Products and parts from Dell.
Technical Information
Number of Screens:
1
Screen Size Class:
22"
Viewable Screen Size:
21.5"
Screen Mode:
Full HD
Screen Surface:
Anti-glare
Panel Technology:
Vertical Alignment (VA)
Response Time:
5 ms
Response Time Details:
  • 5 ms GTG (Fast)
  • 8 ms GTG
Aspect Ratio:
16:9
Pixel Pitch:
0.24000 mm x 0.24000 mm
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Mount Type:
Panel Mount
Backlight Technology:
LED Edgelight System
HDCP Supported:
Yes
Maximum Adjustable Height:
5.12"
Tilt Angle:
-5° to 21°
Swivel Angle:
-173° to 173°
Pivot Angle:
+/-90°
Features:
  • Eye Comfort Technology
  • Anti-glare
  • Security Lock
  • Cable Lock Slot
  • BFR Free
  • PVC Free
  • Arsenic-free Glass
  • Mercury-free
Adjustable Stand:
Yes
Stand Adjustments:
  • Swivel
  • Height
  • Pivot
  • Tilt
Stand Included:
Yes
Glass Hardness:
3H
Operation Hours:
12 Hours/7 Days
Video
Maximum Resolution:
1920 x 1080
Standard Refresh Rate:
100 Hz
Color Supported:
16.7 Million Colors
Native Contrast Ratio:
3,000:1
Brightness:
250 Nit
Color Gamut:
72% NTSC (CIE 1931)
Maximum Preset Resolution:
1920 x 1080 at 100Hz
Pixel Per Inch (PPI):
103
Audio
Number of Speakers:
2
Speakers:
Yes
Speaker Output Power:
4 W
Interfaces/Ports
HDMI:
Yes
HDMI Version:
1.4
VGA:
Yes
DisplayPort:
Yes
Total Number of HDMI Ports:
1
Number of DisplayPorts:
1
Number of VGA Ports:
1
Number of DisplayPort 1.2 (HDCP 1.4):
1
Number of HDMI 1.4 (HDCP 1.4):
1
Environmental Conditions
Operating Temperature Range:
32°F (0°C) to 104°F (40°C)
Non-operating Temperature Range:
-4°F (-20°C) to 140°F (60°C)
Operating Humidity Range:
10% to 80% (Non-condensing)
Non-operating Humidity Range:
5% to 90% (Non-condensing)
Maximum Operating Altitude:
16404 ft
Maximum Non-operating Altitude:
40000 ft
Power Description
Input Voltage Range:
100V AC to 240V AC
Energy Efficiency Class (till 28th February 2021):
D
Frequency:
  • 50 Hz
  • 60 Hz
Voltage Current:
700 mA
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Height:
11.4"
Width:
19.4"
Depth:
2.1"
Height with Stand:
18.45"
Width with Stand:
19.37"
Depth with Stand:
8.33"
Compressed Height with Stand:
13.70"
Extended Height with Stand:
18.45"
Bezel Width (Top):
0.26"
Bezel Width (Bottom):
0.68"
Bezel Width (Left):
0.26"
Bezel Width (Right):
0.26"
Weight (Approximate):
4.98 lb
Stand Height:
15.75"
Stand Width:
10.12"
Stand Depth:
8.33"
Weight with Stand (Approximate):
9.06 lb
Miscellaneous
Energy Star:
Yes
TCO Certified:
Yes
Dell Display and Peripheral Manager Compatibility:
Yes
Remote Asset Management:
DDPM
Application/Usage:
Commercial
Item Numbers
GTIN: 5397184962411
EAN: 5397184962411
UNSPSC: 43211902

Frequently Asked Questions

The Dell E2225HSM features a 21.5-inch Full HD (1920 x 1080) VA panel display with 250 nits brightness, 5ms response time, and 100 Hz refresh rate. The monitor supports a 16:9 aspect ratio with 16.7 million colors, making it suitable for general office and warehouse management applications requiring clear visibility of data and documentation.

The Dell E2225HSM provides multiple connectivity options including HDMI, VGA, and DisplayPort inputs, allowing flexible integration with various computers and devices. These standard video inputs ensure compatibility with most warehouse management systems, IT infrastructure, and legacy equipment commonly found in logistics facilities.

Yes, the Dell E2225HSM is VESA mount compatible with a 100mm mounting interface, allowing you to mount it on walls, monitor arms, or specialized workstations. This flexibility makes it ideal for space-constrained warehouse environments where desk real estate is limited.

The Dell E2225HSM has a maximum power consumption of 50W, with typical operation at 23W and standby mode at 0.5W. This energy-efficient design helps reduce operational costs in warehouse and logistics facilities running equipment continuously throughout shifts.

The Dell E2225HSM operates reliably in temperatures between 5°C and 35°C with humidity levels from 20% to 80% non-condensing. These specifications make it suitable for standard warehouse and office environments, though it may not be ideal for extreme temperature storage or outdoor applications.

Yes, the Dell E2225HSM includes built-in speakers, providing integrated audio capability for video conferencing, training materials, or system alerts without requiring external audio equipment. Contact us today to discuss how this monitor can enhance communication in your warehouse or logistics operation.
