Dell D40D4 Server

Part Number: D40D4
Model: Parts
Add to My Shopping List Add to Compare
$17,135.65
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
1
Number of Processors Installed
1
Processor Manufacturer
Intel
Processor Type
Xeon

Product Description:

  Dell PowerEdge T360 4.5U Tower Server - 1 x Intel Xeon E-2414 2.60 GHz - 16 GB RAM - 480 GB SSD - Serial ATA/600, 12Gb/s SAS Controller - Intel Chip - 1 Processor Support - 128 GB RAM Support - DDR5 SDRAM - Gigabit Ethernet - 8 x Total Bay(s) - 8 x LFF Bay(s) - Hot Swappable Bays - 1 x 600 W
Explore all Dell Misc Parts ACCESSORIES & MISC. ITEMs
Add to Quote
Dell D40D4 Server
Dell D40D4 Server
Dell D40D4 Server
Dell D40D4 Server
Dell D40D4 Server
Dell D40D4 Server Dell D40D4 Server Dell D40D4 Server Dell D40D4 Server Dell D40D4 Server

Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview

Products and parts from Dell.
Dell D40D4 Server Overview

PowerEdge T360 | Deliver powerful compute with a single processor server

The Dell PowerEdge T360 addresses evolving compute demands with an easy-to-manage tower server designed for businesses looking for affordable enterprise features.

Elevate your enterprise to new heights with PowerEdge T360

Powered by the latest Intel® Xeon® E-2400 processors, Dell PowerEdge T360 is an office-friendly tower server designed for productivity and data intensive applications, making it ideal for your growing business. With 4400/MT DDR5 and advanced NVMe BOSS-N1, it supports reduced latency and seamless scalability to bring the computing capability to the next level. Beyond the computing power, the Dell PowerEdge T360 is equipped with energy-efficient power supply, hot-plug storages, air cooling fans to make it a reliable, responsible and secure choice.

Enterprise-level GPU support

The PowerEdge T360 supports NVIDIA A2 GPU to meet the growing demand in video and audio computing. It provides cost-effective solutions for ROBO and Near-Edge customers from retail, manufacturing and logistics. The PowerEdge T360 is ideal for entry-level GPU customers to address business critical workloads including video surveillance, audio encoding and inferencing, and VDI applications.

Cyber Resilient Architecture for Zero Trust IT environment & operations

Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations.

Increase efficiency and accelerate operations with autonomous compute infrastructure

The Dell OpenManage™ systems management portfolio delivers a secure, efficient, and comprehensive solution for PowerEdge servers. Simplify, automate and centralize one-to-many management with the OpenManage Enterprise console and iDRAC.

Sustainability

From recycled materials in our products and packaging, to thoughtful, innovative options for energy efficiency, the PowerEdge portfolio is designed to make, deliver, and recycle products to help reduce the carbon footprint and lower your operation costs. We even make it easy to retire legacy systems responsibly with Dell Technologies Services.

Rest easier with Dell Technologies Services

Maximize your PowerEdge Servers with comprehensive services ranging from Consulting, to ProDeploy and ProSupport suites, Data Migration and more - available across 170 countries and backed by our 60K+ employees and partners.

Processor
Number of Processors Supported:
1
Number of Processors Installed:
1
Processor Manufacturer:
Intel
Processor Type:
Xeon
Processor Model:
E-2414
Processor Core:
Quad-core (4 Core)
Processor Speed:
2.60 GHz
Cache:
12 MB
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
16 GB
Maximum Memory Supported:
128 GB
Memory Technology:
DDR5 SDRAM
Error Checking:
ECC
Total Number of Memory Slots:
4
Signal Processing:
Unregistered (Unbuffered)
Storage
Total Solid State Drive Capacity:
480 GB
Solid State Drive Interface:
Serial ATA/600
Controllers
Controller Type:
  • Serial ATA/600
  • 12Gb/s SAS
Controller Model:
PERC H355
RAID Supported:
No
I/O Expansions
Number of Total Expansion Bays:
8
Number of 3.5" Bays:
8
Number of LFF Bays:
8
Hot Swappable Bays:
Yes
Total Number of Expansion Slots:
4
PCI Express Details:
  • Slot 1: x8 Gen4 Full height, half length
  • Slot 2: x16 Gen5 Full height, half length
  • Slot 3: x1 Gen4 Full height, half length
  • Slot 4: x8 Gen4 Full height, half length
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports:
8
Number of USB 2.0 Ports:
3
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
2
VGA:
Yes
Number of VGA Ports:
1
Remote Management:
Yes
Remote Management Controller:
iDRAC9 Enterprise 16G
Operating System
Operating System Supported:
  • Ubuntu Server
  • Hyper-V
  • Windows Server
  • Red Hat Enterprise Linux
  • SuSE Linux Enterprise Server
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Supported:
2
Number of Power Supplies Installed:
1
Plug/Connector Type:
NEMA 5-15P to C13
Maximum Power Supply Wattage:
600 W
Redundant Power Supply:
No
Hot Swappable Power Supply:
Yes
Power Source:
Power Supply
Physical Characteristics
Form Factor:
Tower
Rack Height:
4.5U
Height:
15.1"
Width:
6.9"
Depth:
22.8"
Miscellaneous
Package Contents:
  • PowerEdge T360 Server
  • Power Cord
Security Features:
  • Cryptographically signed firmware
  • Data at Rest Encryption (SEDs with local or external key mgmt)
  • Secure Boot
  • Secured Component Verification (Hardware integrity check)
  • Secure Erase
  • Secured-core server
  • Silicon Root of Trust
  • System Lockdown (requires iDRAC9 Enterprise or Datacenter)
  • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Warranty
Limited Warranty:
16 Month
Additional Warranty Information:

Next Bus. Day (Disti SNS), 16 Month(s)

Item Numbers
GTIN: 0884116480365
UPC: 884116480365
EAN: 0884116480365
UNSPSC: 43211501

Frequently Asked Questions

The Dell PowerEdge T360 is a 4.5U tower server featuring a single Intel Xeon E-2414 processor running at 2.60 GHz, 16 GB of DDR5 SDRAM standard memory (expandable to 128 GB), and a 480 GB SSD with Serial ATA/600 and 12Gb/s SAS controller support. It includes 8 large-form-factor (LFF) hot-swappable bays and a 600W power supply, making it suitable for small to medium business environments. We offer this server as part of our comprehensive IT infrastructure solutions.

Yes, the Dell PowerEdge T360 is well-suited for warehouse and logistics operations requiring reliable server infrastructure for inventory management, barcode scanning systems, and RFID data processing. Its hot-swappable bays and scalable memory support enable easy maintenance and growth as your operation expands. Contact us today to discuss how we can integrate this server with your existing AIDC systems and warehouse management software.

The Dell D40D4 supports up to 128 GB of DDR5 SDRAM memory and features 8 large-form-factor hot-swappable bays for storage expansion. The server comes standard with a 480 GB SSD but can be configured with additional drives to meet your data retention and performance requirements. We can help you customize the configuration based on your specific warehouse or logistics needs.

The Dell D40D4 includes Gigabit Ethernet connectivity for reliable network communication in your facility. This enables seamless integration with barcode scanners, mobile computers, label printers, and other AIDC devices we offer. Visit barcodesinc.com to explore networking options that complement your server infrastructure.

Yes, the Dell PowerEdge T360's Intel Xeon E-2414 processor and up to 128 GB of expandable DDR5 memory make it capable of managing multiple simultaneous connections from barcode scanners, mobile computers, and RFID readers in a warehouse environment. The Gigabit Ethernet connectivity ensures stable communication across your AIDC infrastructure. Contact us today to discuss server sizing for your specific device count and throughput requirements.

While specific environmental certifications for the D40D4 are not detailed in our current specifications, Dell's enterprise servers are built to industry standards for reliability and data center operation. For detailed compliance information regarding ENERGY STAR, EPEAT, or other environmental certifications relevant to your facility, we recommend contacting our team today to review the complete technical documentation.
