Dell CTP9K Desktop PC
Part Number:
CTP9K
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell CTP9K Desktop PC Overview
Dell Pro Max Slim Desktop
Experience unparalleled speed with incredibly fast CPU and GPU performance, now in an 8.5L design.
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core Ultra 9
Processor Model:
285
Processor Core:
Tetracosa-core (24 Core)
Processor Threads:
24
Processor Speed:
2.50 GHz
Maximum Turbo Speed:
5.70 GHz
NPU Manufacturer:
Intel
NPU Name:
AI Boost
NPU Performance:
13 TOPS
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
32 GB
Maximum Memory Supported:
128 GB
Memory Technology:
DDR5 SDRAM
Memory Configuration:
1 x 32GB
Number of Occupied Memory Slots:
1
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
1 TB
Solid State Drive Interface:
PCI Express NVMe 4.0
SSD Form Factor:
M.2
Display & Graphics
Graphics Controller Manufacturer:
NVIDIA
Graphics Controller Model:
RTX 2000 Ada
Graphics Memory Capacity:
Up to 16 GB
Graphics Memory Technology:
GDDR6
Graphics Memory Accessibility:
Dedicated
Network & Communication
Ethernet Technology:
Ethernet
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11be
Bluetooth:
Yes
Interfaces/Ports
Total Number of USB Ports:
10
Number of USB 2.0 Ports (Front):
2
Number of USB 2.0 Ports (Rear):
2
Number of USB 3.2 Gen 1 Ports:
3
Number of USB 3.2 Gen 2 Ports:
1
Number of USB 3.2 Gen 2x2 Type-C Ports:
1
USB Type-C (Rear):
Yes
USB Type-C Detail:
1 USB 3.2 Gen 2 Type-C® (10Gbps) port
Number Of Ethernet Ports:
1
Number of DisplayPort Outputs (Rear):
3
DisplayPort (Rear):
Yes
Optional Ports:
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 Optional port (VGA, HDMI 2.1 FRL, DisplayPort™ 2.1 UHBR20, USB 3.2 Gen 2 (10Gbps), USB 3.2 Gen 2 (10Gbps) Type-C®with DisplayPort™ Alt Mode port, Thunderbolt™ 4 port, Type-C®Data only Gen 2x1 (10Gbps) port, LC Fiber optic port)
- 1 Legacy serial port
- 1 RJ45 (5GbE) Ethernet port
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Power Description
Maximum Power Supply Wattage:
360 W
Physical Characteristics
Cooler Type:
Air Cooler
Form Factor:
Slim PC
Height:
11.9"
Width:
3.7"
Depth:
11.5"
Weight (Approximate):
8.75 lb
Miscellaneous
Package Contents:
- Pro Max FCS1250 Desktop Computer
- Power Cord
- 4 x mDP to DP Adapters
- Quick Setup Guide
Systems Management:
Intel vPro Standard Management
Energy Star:
Yes
Country of Origin:
Mexico
TCO Certified:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116490715
UPC:
884116490715
EAN:
0884116490715
UNSPSC:
43211507
Frequently Asked Questions
What are the key specifications of the Dell CTP9K Desktop PC?
The Dell CTP9K is a slim desktop computer featuring an Intel Core Ultra 9 285 processor, 32 GB of memory, and a 1 TB SSD for fast storage and boot times. It includes an NVIDIA RTX 2000 Ada with 16 GB GDDR6 graphics memory, Windows 11 Pro, IEEE 802.11be wireless connectivity, and a 360 W power supply. This configuration makes it suitable for demanding professional workloads in warehouse management and logistics operations.
Is the Dell CTP9K suitable for warehouse and logistics management software?
Yes, the Dell CTP9K is well-suited for warehouse and logistics applications with its powerful Intel Core Ultra 9 285 processor and 32 GB of RAM, which can handle complex inventory management systems and real-time data processing. The 1 TB SSD ensures quick application loading and responsiveness for mission-critical warehouse operations. Contact us today to discuss your specific software requirements and ensure compatibility.
What graphics capabilities does the Dell CTP9K offer?
The Dell CTP9K features an NVIDIA RTX 2000 Ada discrete graphics card with 16 GB of GDDR6 memory, providing excellent performance for visualization-intensive applications and multi-monitor setups common in logistics command centers. This professional-grade GPU supports advanced rendering and data visualization tasks beyond standard office computing. Visit barcodesinc.com to learn more about display and graphics options available with this system.
What wireless and network connectivity options does the Dell CTP9K provide?
The Dell CTP9K includes IEEE 802.11be wireless LAN for high-speed wireless connectivity and supports standard network connectivity for enterprise environments. The 802.11be standard provides the latest Wi-Fi 7 technology for reliable connections in warehouse and logistics facilities. We offer this system configured for seamless integration into your existing IT infrastructure.
Can the Dell CTP9K handle multiple displays for warehouse management operations?
Yes, the Dell CTP9K with its NVIDIA RTX 2000 Ada graphics and multiple connectivity options can support multi-display configurations typical in warehouse command centers and logistics control rooms. The dedicated graphics memory and professional GPU ensure smooth performance across multiple monitors for real-time tracking and inventory management. Contact us today for multi-display configuration recommendations.
What operating system and security features does the Dell CTP9K include?
The Dell CTP9K comes with Windows 11 Pro, which includes enhanced security features and management capabilities suitable for enterprise warehouse environments. Windows 11 Pro provides better control over system updates, user permissions, and integration with enterprise security tools commonly used in logistics operations. Visit barcodesinc.com for information on additional security configurations and deployment options.
