Dell 802YX Workstation PC
Part Number:
802YX
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell 802YX Workstation PC Overview
Thin, powerful, and built for portability
The Dell Pro Max 16 combines performance and portability to deliver exceptional value. Powered by AMD Ryzen processors, it offers outstanding battery life and seamless on-device AI experiences.
Technical Information
Processor
Processor Manufacturer:
AMD
Processor Type:
Ryzen AI 7 PRO
Processor Model:
350
Processor Core:
Octa-core (8 Core)
Processor Threads:
16
Maximum Turbo Speed:
5 GHz
Total AI Performance:
66 TOPS
NPU Manufacturer:
AMD
NPU Name:
Ryzen AI
NPU Performance:
50 TOPS
Chipset
Chipset Manufacturer:
AMD
Memory
Standard Memory:
32 GB
System Memory Form Factor:
On-board
On-board Memory:
32 GB
On-board Memory Technology:
LPDDR5X
On-board Memory Configuration:
1 x 32GB
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
SSD Form Factor:
M.2
Display & Graphics
Screen Size:
16"
Display Screen Type:
LCD
Screen Mode:
Full HD Plus
Brightness:
300 Nit
Color Gamut:
45% NTSC
Touchscreen:
No
Graphics Controller Manufacturer:
NVIDIA
Graphics Controller Model:
RTX PRO 500
Graphics Memory Capacity:
6 GB
Graphics Memory Technology:
GDDR7
Graphics Memory Accessibility:
Dedicated
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11be
Wi-Fi Generation:
Wi-Fi 7
Ethernet Technology:
Gigabit Ethernet
Bluetooth:
Yes
Built-in Devices
Camera Privacy Shutter:
Yes
Front Camera/Webcam:
Yes
Finger Print Reader:
Yes
Speaker Power Details:
2 x 2W
Sound Mode:
Stereo
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
2
Number of USB 3.2 Gen 1 Type-A Ports:
2
Number Of Ethernet Ports:
1
Network (RJ-45):
Yes
Number of Thunderbolt 4 Ports:
2
Optional Ports:
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 Smart-card reader slot (optional)
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/Spanish/French/Brazilian Portuguese
Input Devices
Keyboard Backlight:
Yes
Keyboard Localization:
English (US)
Copilot Key:
Yes
Battery Information
Number of Cells:
6-cell
Power Description
Power Plug Type:
Type C
Included Charger Power:
130 W
USB Power Delivery Support:
Yes
Physical Characteristics
Color Family:
Other
Product Color:
Magnetite
Height:
1.01"
Width:
14.1"
Depth:
10.1"
Weight (Approximate):
4.59 lb
Miscellaneous
Package Contents:
- Pro Max 16 MC16255
- Lithium Polymer Battery
- AC Adapter
- Power Cord
- Documentation
- Quick Setup Guide
Charger Included:
Yes
Features:
- Anti-glare Screen
- ExpressCharge
Energy Star:
Yes
Country of Origin:
Vietnam
TCO Certified:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
- Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
- Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116672029
UPC:
884116672029
EAN:
0884116672029
UNSPSC:
43211503
Frequently Asked Questions
What processor and RAM does the Dell 802YX workstation include?
The Dell Pro Max MC16255 features an AMD Ryzen AI 7 PRO 350 processor paired with 32 GB of memory, delivering robust performance for professional workloads. This configuration is ideal for warehouse management systems, logistics software, and data-intensive applications that require reliable multitasking capabilities.
Is the Dell 802YX suitable for field operations and mobile use?
Yes, the Dell Pro Max MC16255 is designed as a mobile workstation with a 16" Full HD Plus display, making it portable for field teams and logistics professionals who need to work on-site. The Wi-Fi 7 (IEEE 802.11be) connectivity ensures fast, reliable connections for real-time data synchronization in warehouse and distribution environments.
What graphics capabilities does this Dell workstation offer?
The Dell 802YX includes an NVIDIA RTX PRO 500 Blackwell GPU with 6 GB of dedicated memory, providing professional-grade graphics performance for CAD, visualization, and data analysis tasks. This discrete graphics solution ensures smooth performance even with demanding applications used in logistics planning and warehouse optimization.
What storage options are available on the Dell 802YX?
The Dell Pro Max MC16255 comes standard with a 512 GB SSD, offering fast boot times and application responsiveness critical for warehouse operations. SSDs provide superior reliability compared to traditional hard drives, reducing downtime in mission-critical logistics environments.
Does the Dell 802YX meet enterprise security and OS requirements?
Yes, the Dell 802YX runs Windows 11 Pro, which provides enterprise-grade security features, BitLocker encryption, and domain management capabilities essential for IT procurement in large warehouse and logistics operations. This OS ensures compatibility with enterprise resource planning (ERP) and warehouse management system (WMS) software.
