Dell 6NRNF Laptop
Part Number:
6NRNF
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell 6NRNF Laptop Overview
Work anywhere on our most scalable and sustainable Latitude
Work confidently on this new 14" business laptop that combines ultimate performance, scalability and security. The 5000 Series is Latitude's most sustainable series ever.
Features & Design | Operating system
Available with Windows 11 Pro.
The confidence to work anywhere | ExpressConnect
Be on 2 networks at once with the world's first simultaneous multi-network connection for faster data and video downloads Get up to 20% more in data transfer from optimized networking, 30% faster application data processing and 8 times better video quality from optimized internet bandwidth.
Technical Information
Processor
Processor Manufacturer:
Intel
Processor Type:
Core i5
Processor Generation:
12th Gen
Processor Model:
i5-1245U
Processor Core:
Deca-core (10 Core)
Processor Speed:
1.60 GHz
Maximum Turbo Speed:
4.40 GHz
vPro Technology:
Yes
Chipset
Chipset Manufacturer:
Intel
Memory
Standard Memory:
16 GB
Maximum Supported System Memory:
64 GB
System Memory Technology:
DDR4 SDRAM
System Memory Speed:
3200 MHz
Installed Slot Memory Configuration:
2 x 8GB
Total Number of Memory Slots:
2
Number of Occupied Memory Slots:
2
Number of Free Memory Slots:
0
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
SSD Form Factor:
NVMe M.2 PCI Express
Optical Drive Type:
No
Display & Graphics
Screen Size:
14"
Display Screen Type:
LCD
Standard Refresh Rate:
60 Hz
Screen Mode:
Full HD
Screen Resolution:
1920 x 1080
Touchscreen:
No
Graphics Controller Manufacturer:
Intel
Graphics Controller Model:
Iris Xe Graphics
Graphics Memory Technology:
DDR4 SDRAM
Graphics Memory Accessibility:
Shared
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11ax
Ethernet Technology:
Ethernet
Bluetooth:
Yes
Built-in Devices
Front Camera/Webcam:
Yes
Infrared Camera:
Yes
Finger Print Reader:
Yes
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
2
Number of USB 3.2 Gen 1 Ports:
2
Network (RJ-45):
Yes
Number of Thunderbolt 4 Ports:
2
Optional Ports:
1 TBT4/USB 3.2 Gen 2 Type-C® port with PowerDelivery 3.0 (optional) 1 Optional I/O bay (Choose from: RJ-45/USB Type-A/Native Serial/Fischer USB 3.0 9-pin/Blank)
Details regarding optional ports aggregated from the information available for this product's family/series
Operating System
Operating System Platform:
Windows
Operating System:
Windows 10 Pro
Upgradable Operating System:
Windows 11 Pro
Operating System Language:
English/French/Spanish
Input Devices
Keyboard Backlight:
Yes
Keyboard Localization:
English (US)
Battery Information
Number of Cells:
4-cell
Power Description
Maximum Power Supply Wattage:
65 W
Physical Characteristics
Color Family:
Gray
Product Color:
Gray
Height:
0.76"
Width:
12.7"
Depth:
8.3"
Weight (Approximate):
3 lb
Miscellaneous
Package Contents:
- Latitude 5430
- Standard Battery
- AC Adapter
- Power Cord
- Safety/Environment And Regulatory Guide
- Quick Start Guide
Features:
Anti-glare Screen
Energy Star:
Yes
Country of Origin:
China
TCO Certified:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Energy Efficiency Certification:
China Energy Conservation Program (CECP)
Warranty
Limited Warranty:
1 Year
Additional Warranty Information:
1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis (Disti SNS)
Item Numbers
UNSPSC:
43211503
Frequently Asked Questions
What are the memory and storage specifications for the Dell 6NRNF Latitude 5430?
The Dell 6NRNF comes standard with 16GB of DDR3 SDRAM across 2 DIMM slots and 512GB solid-state storage. The system supports up to 8GB per DIMM slot for maximum expandability, and storage options range from traditional hard drives up to 750GB or encrypted solid-state drives for enhanced security and performance.
Is the Dell 6NRNF suitable for warehouse and logistics operations?
Yes, the Dell 6NRNF Latitude 5430 is well-suited for warehouse and logistics environments with its rugged design, optional impact-resistant protective front glass, and Dell Fast Response Free Fall Sensor with HDD isolation for drop protection. The 14-inch display with 1920x1080 resolution provides clear visibility for scanning and data entry tasks in demanding work conditions.
What connectivity options does the Dell 6NRNF laptop provide?
The Dell 6NRNF offers comprehensive connectivity including USB/eSATA combo ports, HDMI, RJ-45 network connector, stereo headphone/microphone combo jack, and optional USB 3.0 modules via media bay expansion. Additional security connectivity includes SmartCard reader support and optional contactless SmartCard reader for enterprise authentication requirements.
What security features are built into the Dell 6NRNF?
The Dell 6NRNF includes multiple security layers: SmartCard reader, optional fingerprint reader, TPM 1.2 chip, ControlVault technology, and optional Intel vPro management capabilities. Physical security features include cable lock slots and battery/hard drive locks, while encrypted storage options support FIPS Opal full-disk encryption for sensitive data protection.
What are the battery and power options for the Dell 6NRNF?
The Dell 6NRNF offers three lithium-ion battery configurations: a 6-cell 60Wh battery for standard use, a 9-cell 97Wh battery for extended runtime, and a 9-cell 87Wh option with 3-year limited hardware warranty. All batteries feature ExpressCharge technology for faster charging, and a second battery can be installed via the E-Module Bay II for continuous operation.
How durable is the Dell 6NRNF for field use in logistics environments?
The Dell 6NRNF is engineered for rugged field operations with impact-resistant protective front glass, free fall sensor protection, and optional rubberized keyboard for durability in harsh conditions. It weighs approximately 8.8 lbs with the 6-cell battery, making it portable for mobile warehouse and logistics professionals, and meets ENERGY STAR 5.0 and EPEAT environmental standards for sustainable operations.
