Application/Usage:
- Data Networking
- Optical Network
Dell 407-BBVN Transceiver Modules
Part Number:
407-BBVN
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell 407-BBVN Transceiver Modules Overview
The Dell™ QSFP28 transceiver delivers fiber connectivity to extend the range of your network. This hot-pluggable transceiver with QSFP28 (Small Form Factor Pluggable) footprint features a Duplex LC connector. The Dell networking 100GbE, OM3/OM4 MMF QSFP28 transceiver provides 100GbE connectivity up to 100 m.
Additionally, it provides a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power, and transceiver supply voltage.
Additionally, it provides a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power, and transceiver supply voltage.
Technical Information
Interfaces/Ports
Total Number of Ports:
1
Connector Type:
LC
Interfaces/Ports Details:
1 x LC Duplex 100GBase-SWDM4 Network
Media & Performance
Media Type Supported:
Optical Fiber
Fiber Mode Supported:
Multi-mode
Ethernet Technology:
100 Gigabit Ethernet
Network Technology:
100GBase-SWDM4
Physical Characteristics
Form Factor:
- Plug-in Module
- Hot-pluggable
Miscellaneous
Compatibility:
Dell EMC Switches:
- S5212F-ON
- S5224F-ON
Item Numbers
GTIN:
0884116464372, 5397184377161
UPC:
884116464372
EAN:
0884116464372, 5397184377161
UNSPSC:
43201553
Frequently Asked Questions
What is the Dell 407-BBVN transceiver module used for?
The Dell 407-BBVN is a QSFP28 networking transceiver designed for high-speed data networking applications requiring 100 Gigabit Ethernet connectivity. It supports the 100GBase-SWDM4 standard over multi-mode optical fiber, making it ideal for data center and enterprise network infrastructure. We offer this module as a hot-pluggable component that integrates seamlessly into compatible Dell networking equipment.
What are the specifications for the Dell 407-BBVN transceiver?
The Dell 407-BBVN is a QSFP28 transceiver that delivers 100 Gigabit Ethernet speeds using SWDM4 (Short Wavelength Division Multiplexing) technology over OM3/OM4 multi-mode fiber. It supports transmission distances up to 100 meters and features LC Duplex connectors for optical fiber connections. Contact us today for detailed technical specifications and compatibility information for your network infrastructure.
Is the Dell 407-BBVN hot-pluggable?
Yes, the Dell 407-BBVN is a hot-pluggable transceiver module, meaning it can be safely inserted or removed from compatible equipment without powering down the system. This design allows for flexible network configuration and maintenance without service interruptions. Available from us for immediate deployment in your data center environment.
What fiber types does the Dell 407-BBVN support?
The Dell 407-BBVN transceiver is designed for multi-mode optical fiber and is compatible with both OM3 and OM4 fiber standards. It supports transmission distances up to 100 meters on these multi-mode fiber types, making it suitable for intra-data center and campus network applications. Visit barcodesinc.com to verify compatibility with your existing fiber infrastructure.
What connector type does the Dell 407-BBVN use?
The Dell 407-BBVN features LC Duplex connectors for optical fiber connections, which is the standard connector type for QSFP28 transceiver modules in enterprise networking. The LC Duplex design provides reliable, compact connections suitable for high-density network equipment. We offer this transceiver with all necessary connectors and compatibility assurances for your network deployment.
What networking standards does the Dell 407-BBVN support?
The Dell 407-BBVN supports 100 Gigabit Ethernet using the 100GBase-SWDM4 standard, which is optimized for short-wavelength transmission over multi-mode fiber. This standard is widely deployed in modern data center networks requiring high-speed, cost-effective connectivity. Contact us today to discuss how this transceiver fits into your network architecture and upgrade plans.
