Datamax-O'Neil I13-00-46000007 Barcode Printer


0.0

(No reviews)

Be the first to

Write a Review
Datamax-O'Neil I-4310e Mark II - 4"-300 dpi, 10 IPS, THERMAL TRANSFER BARCODE PRINTER WITH SERIAL, PARALLEL, USB, Real-time clock, MEDIA HUB, BRITISH & EUROPEAN PLUG
Versatility that will increase productivity.

Datamax-O-Neil"s I-Class revolutionized the barcode printer industry with its award winning modular design, field installable options and rugged reliability. For the past several years, resellers have named the I-Class the "best channel product" in some of the industry"s largest third-party surveys. Now we"ve raised the bar even higher, with the redesigned I-4310e Mark II.

Technical Information

  • Maximum Mono Print Speed: 10 in/s
  • Maximum Print Resolution: 300 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.16"
  • Recommended Use: Label Print
  • Features:
    • Real Time Clock
    • Media Supply Hub
    • Rotate Printing
    • Mirror Printing
  • Barcode Symbology Supported:
    • Data Matrix
    • POSTNET
    • PDF-417
    • Interleaved 2 of 5
    • UCC/EAN 128
    • Code 16K
    • Code 11
    • Code 3 of 9
    • Code 128
    • Codabar
    • Code 93
    • Micro PDF-417
    • Industrial 2 of 5
    • Telepen
    • UPC-E
    • EAN/JAN-8
    • UPC-A
    • EAN/JAN-13
    • Standard 2 of 5
    • Plessey
    • USD-8
    • Planet Code
    • HIBCC
    • TLC 39
    • GS1 DataBar
    • Maxi Code
    • QR Code
    • Aztec Code
    • FIM

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Brand Name: Datamax-O'Neil
  • Manufacturer: Datamax-O'Neil
  • Product Model: I-4310e
  • Product Name: I-Class Mark II I-4310e Label Printer
  • Product Line: I-Class

Physical Characteristics

  • Height: 12.7"
  • Width: 12.6"
  • Depth: 18.6"
  • Form Factor: Desktop
  • Weight (Approximate): 45.20 lb

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes
  • Parallel Port: Yes

Media Types & Handling

  • Maximum Label Width: 4.65"
  • Media Type:
    • Continuous Paper
    • Continuous Form
    • Fanfold
    • Perforated Label
    • Die-cut Label
    • Tag Stock
    • Ticket
    • Label
  • Media Thickness: 10 mil
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 8"

Memory

  • Standard Memory: 32 MB
  • Memory Technology: SDRAM
  • Flash Memory: 64 MB

Fonts & Emulation

  • Language Emulation: DPL

Other

  • Platform Supported: PC

Display & Graphics

  • Display Screen Type: LCD

Power Description

  • Power Source: AC Supply

Full specifications (PDF)

Full specifications (PDF)

Brand Datamax-O'Neil
Model I-4310e Mark II
Print Method Thermal Transfer
Label Core 1.5 inches, 3 inches
Print Speed 10
Max Label Width 4.65
Maximum Print Width 4.65, 4.16
Interface Options Serial, Parallel, USB
Max Roll Outer Diameter 8
Printer Type Industrial
Print Resolution 300 dpi
Printer Mobility Not Mobile
Ribbon Core 1
