Datamax-O'Neil W-6308 – Barcode Label Printer – 305 dpi – Thermal Transfer

Part Number: G63-00-31000007
Model: W-6308
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Parallel, Serial (RS-232)
Print Resolution
305 dpi

Product Description:

  W-6308 Direct Thermal-Thermal Transfer Printer (300 dpi, 6 Inch Print Width, 8 ips Print Speed, Serial and Parallel Interfaces, Coated Side Out with Static Brush)
Explore all Datamax-O'Neil W-6308 Barcode Label Printers
Add to Quote
Datamax-O'Neil G63-00-31000007 Barcode Label Printer
Datamax-O'Neil G63-00-31000007 Barcode Label Printer
Datamax-O'Neil G63-00-31000007 Barcode Label Printer Datamax-O'Neil G63-00-31000007 Barcode Label Printer
Full specifications (PDF)

Datamax-O'Neil W-6308 Barcode Label Printer Model Overview

The W-6308 features a tough all-metal chassis designed to withstand adverse work environments making it ideal for heavy-duty industrial applications. The W-6308 is equipped with a 32-bit 90-MHz true multi-tasking Motorola ColdFire processor and 16MB of standard memory, which provides accelerated first-label output and variable-data printing. It is an ideal printer for compliance labeling applications including ODETTE, EAN-128 and AIAG labels. All units ship with product documentation.
Datamax-O'Neil G63-00-31000007 Barcode Label Printer Overview

The W-6308 Thermal Barcode Printer is designed to address the specialized printing needs of applications where wide label formats are industry standard requirements. It features more standard memory, a fast processor and the scalability required in today's connected workplace. W-6308 includes a card cage with the option to add accessories anytime and on-site. It is constructed to endure the most intense industrial printing environments, with an all metal chassis and heavy duty metal exterior designed to protect the value of your technology investment. When it comes to reliability, ease of use, maintenance and high performance, there is just one choice, the Datamax W-6308. It is the the most affordable, high performance, heavy duty, mission critical, wide web thermal printer in today's market.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
8 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
6.40"
Barcode Symbology Supported:
  • Micro PDF-417
  • TLC 39
  • Aztec Code
  • QR Code
  • Data Matrix
  • USD-8
  • PDF-417
  • FIM
  • UPS MaxiCode
  • Telepen
  • UCC/EAN 128
  • POSTNET
  • Code 93
  • Plessey
  • Codabar
  • HIBC
  • EAN-13
  • EAN-8
  • Code 128
  • Interleaved 2 of 5
  • UPC-A
  • UPC-E
Application/Usage:
Desktop
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
2 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
Media Types & Handling
Media Type:
  • Fanfold
  • Die-cut Label
  • Continuous Label
  • Perforated Label
  • Continuous Tag
  • Ticket Stock
  • Roll Fed
Media Sensor:
  • Reflective Media Sensor
  • Transmissive Media Sensor
Media Thickness:
10 mil
Maximum Roll Diameter:
7.99"
Ribbon Core Size:
0.98"
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
14.8"
Width:
13.8"
Depth:
18.5"
Miscellaneous
Additional Information:
  • 32-bit, 90-MHz, true multi-tasking processor
  • Simple loading of media and ribbon
  • 20 character LCD display
  • Printhead mechanism is hinged to provide wide-open access.
  • Revolving media hubs available in 1.5" and 3" sizes.
  • Metal construction, clear side window to easily monitor media supply levels.
Item Numbers
UNSPSC: 43212108
