Datamax-O'Neil 210191-101 Accessory
Frequently Asked Questions
What ribbon options are available for the Fargo 045500 ID Card Printer?
The Fargo 045500 supports multiple ribbon configurations including full-color YMCKO (250 prints), full-color half-panel YMCKO (350 prints), full-color with dual resin black YMCKOK (200 prints), resin black and overlay KO (500 prints), dye-sublimation black and overlay BO (500 prints), and single-color resin options in black, green, blue, red, white, silver, and gold (1000 prints each). All ribbons include an integrated cleaning roller that is automatically replaced with each new ribbon cartridge.
What print speeds can I expect with the Fargo 045500?
Print speeds vary depending on ribbon configuration: 7 seconds per card for single resin black (K), 12 seconds per card for resin black with overlay (KO), 24 seconds per card for full-color YMCKO, and 31 seconds per card for dual-resin full-color YMCKOK. These speeds make the Fargo 045500 suitable for both low-volume and moderate-volume ID card production environments.
What card sizes and thicknesses does the Fargo 045500 support?
The Fargo 045500 accepts standard CR-80 cards (3.375" x 2.125" / 85.6mm x 54mm) and CR-79 adhesive back cards (3.313" x 2.063" / 84.1mm x 52.4mm). The printer supports card thickness from 0.009" to 0.040" (9 mil to 40 mil / 0.229mm to 1mm), providing flexibility for various card stock options.
What is the print resolution and color capability of the Fargo 045500?
The Fargo 045500 delivers 300 dpi (11.8 dots/mm) continuous-tone resolution with support for up to 16.7 million colors and 256 shades per pixel. This high resolution and color depth enables detailed, photo-quality ID card printing suitable for professional badge and credential applications.
What are the operating environment requirements for the Fargo 045500?
The Fargo 045500 operates optimally in temperatures between 65° to 80°F (18° to 27°C) with humidity levels of 20–80% non-condensing. These environmental specifications ensure consistent print quality and reliable ribbon performance in standard office and warehouse settings.
Can the Fargo 045500 ribbon be used with other Fargo printer models?
The Fargo 045500 is an EZ YMCKO cartridge ribbon designed specifically for compatible Fargo ID card printers. We recommend verifying your printer model's compatibility before ordering. Contact us today at barcodesinc.com to confirm compatibility with your specific Fargo printer system and find the right ribbon solution for your operation.
