Datalogic QuickScan Lite QW2170 – Barcode Scanner – Corded – 1D – Scanner Only

Part Number: QW2170-BK-RM
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Scanner Capability
1D
Scanner Type
CCD, Imager

Product Description:

  Corded Barcode Scanner, Datalogic QuickScan Lite QW2170, 1D Linear Imager, General Purpose, Handheld, RS-232 Serial/Keyboard Wedge Connection, SCANNER ONLY, Black, 400 Scans/Second, Remote Management

Datalogic QuickScan QW2100 Barcode Scanner Model Overview

The Datalogic QW2100 imager is small, lightweight and its ergonomic design is comfortable to use during daily operations. It is perfect for use in retail, light manufacturing, document/bill processing and banking/finance environments. The QW2100 offers snappy reading performance on most 1D bar codes and features a wide scanning angle with an extended scanning line which is ideal for capturing longer and wider bar codes typically found on utility bills and used by manufacturers of electronic parts. Additionally, the scanning line on the QW2100 is thinner and brighter, allowing users to scan at wide angles without having to increase the scanning distance.
Datalogic QW2170-BK-RM Barcode Scanner Overview
The QuickScan™ reader series is Datalogic ADC's value line of general purpose handheld data collection products. The QuickScan Lite QW2100 linear imager is an entry level product created specifically for reading long and truncated bar codes which is common in some areas of the world. It is perfect for use in retail, light manufacturing, document/bill processing and banking/finance environments.
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
1D / Linear Codes:
  • Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes
Postal Codes:
  • Australian Post
  • British Post
  • Canadian Post
  • China Post
  • Japanese Post
  • KIX Post
  • Korea Post
  • Planet Code
  • Postnet
  • Royal Mail Code (RM4SCC)
Stacked Codes:
  • EAN/JAN Composites
  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
Image Sensor Type:
Imager
Scan Rate:
400 scan/s
Maximum Scan Resolution:
4 mil
Depth of Field:
Scan Pattern:
Omni-directional
Interfaces/Ports
Host Interface:
  • Serial
  • Keyboard Wedge
Physical Characteristics
Form Factor:
Handheld
Product Color:
Black
Height:
6.7"
Width:
2.6"
Depth:
2.8"
Weight (Approximate):
4.20 oz
Miscellaneous
Additional Information:

USB Cable separate

Country of Origin:
Vietnam
Item Numbers
UNSPSC: 43211701
