Datalogic PM9600 – Barcode Scanner

Part Number: PM9600-DHP910RBK20
Model: PM9600
3-year Premium Plus ($127.97)
3-year Premium ($73.27)
No Support
Add to My Shopping List Add to Compare
$991.93
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Scanning Capability
1D2D
Barcode Symbology Supported
1D Codes: Auto discriminates all standard 1D codes including GS1 DataBar linear codes.2D Codes: Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot codePostal Codes: Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish PostStacked Codes: EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E CompositesDigital Watermarking Digimarc Barcodes (HP and DC models)
Light Source
LED

Product Description:

  Barcode Scanners, Datalogic PM9600, High Performance, 910Mhz, Display/4-Key Keypad, Removeable Battery, RS-232 Kit (Kit Includes Scanner, Cradle BC9630-910, Cable CAB-548, Power Supply 8-0935 And Power Cord 6003-0941)
Explore all Datalogic PM9600 Barcode Scanners
Add to Quote
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner
Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner Datalogic PM9600-DHP910RBK20 Barcode Scanner
Full specifications (PDF)

Datalogic PM9600 Barcode Scanner Model Overview

The PowerScan™ PM9600 Datalogic handheld industrial scanner offers unparalleled performance in 1D/2D barcode reading, seamlessly integrating into tough industrial environments. With its ultra-rugged design and ergonomic shape, this scanner minimizes operator strain while maximizing efficiency. The intuitive aiming system guarantees high first-pass reading rates, while the cordless model, featuring Datalogic's STAR Cordless System™, ensures freedom of movement and safety. Its advanced battery life management allows for multiple shifts of intensive scanning, making it the ideal choice for manufacturing, warehousing, and logistics operations.


Key Features
  • Ultra-Rugged Design for industrial durability
  • Ergonomic Shape that reduces operator stress
  • Advanced Aiming System for highest first-pass reading rates
  • Datalogic's STAR Cordless System™ for improved mobility
  • Wireless Charging System for hassle-free maintenance
  • IP65 and IP67 Ratings for water and dust resistance

Specifications
  • Communication: Datalogic STAR Cordless System™, 433/910 MHz
  • Reading Capability: 1D, 2D, Postal Codes, Stacked Codes
  • Display: 1.8" OLED with user-selectable font dimensions
  • Battery: Lithium-Ion, 3350 mAh
  • Weight: PM9600-D/DK: 425g - 455g
  • Operating Temperature: -20°C to 50°C
  • Drop Resistance: Withstands 50 drops from 2.5m
  • Warranty: 3-Year Factory Warranty
Datalogic PM9600-DHP910RBK20 Barcode Scanner Overview

ULTRA-RUGGED WITH NEW BALANCED ERGONOMICS:

The PowerScan family of bar code readers are the ultimate industrial handheld scanners designed and constructed to withstand the toughest environmental conditions. The PowerScan 9600 imagers have an ultra-rugged design, an ergonomic shape with well-balanced weight to reduce operator stress during daily activities and an intuitive aiming system, allowing the highest first-pass reading rate while reducing unnatural wrist movement.

MOBILITY ENHANCES PRODUCTIVITY:

MOBILITY ENHANCES PRODUCTIVITY The PowerScan 9600 cordless model further enhances the operator efficiency and safety with Datalogic's STAR Cordless System. Accurate power management allows long lasting battery life to always guarantee more than one shift of intensive scanning. The PowerScan 9600 scanner features Datalogic's Wireless Charging System. Based on inductive-charging technology, Datalogic's Wireless Charging System eliminates battery contacts and pins that often get dirty, bent, or broken over time - and this removes a key point of failure for devices used in industrial and retail functions

MODULARITY WITH THE BEST FLEXIBILITY:

The BC9600 base/charger has a modular design and is available with multiple interface plug-ins for standard and industrial communication, such as RS-232, USB, Standard Ethernet and Industrial Ethernet protocols.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D Codes:

  • Auto discriminates all standard 1D codes including GS1 DataBar linear codes.

2D Codes:

  • Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot code

Postal Codes:

  • Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post

Stacked Codes:

  • EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Digital Watermarking

  • Digimarc Barcodes (HP and DC models)
Light Source:
LED
Image Sensor Type:
Imager
Scan Mode:
Trigger
Scan Pattern:
Omni-directional
Scanning Distance:
95.60"
Features:
  • Vibration
  • 3GL
  • Beep
  • Notification LED
  • Ergonomic Design
Number of Keys:
4
Cable Type Included:
Serial
Field of View (Horizontal):
38°
Field of View (Vertical):
24°
Reading Angle (Skew):
52°
Reading Angle (Pitch):
52°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
  • Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
  • Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F
Minimum Print Contrast:
15%
Minimum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
White
Air Electrostatic Discharge (+/-):
20kV
Network & Communication
Radio Frequency:
Yes
Interfaces/Ports
Host Interface:
Serial
Power Description
Power Supply Included:
Yes
Input Current:
480 mA
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Capacity:
3350 mAh
Maximum Battery Recharge Time:
3.20 Hour
Environmental Conditions
Operating Temperature:
-4°F (-20°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
0% to 95%
Physical Characteristics
Form Factor:
Handheld
Rugged:
Yes
Color Family:
Dual Color
Product Color:
  • Black
  • Yellow
Durability:
Water Resistant
Height:
7.8"
Width:
3.1"
Length:
5.5"
Weight (Approximate):
15.70 oz
Miscellaneous
Package Contents:
  • 1 x Powerscan PM9600 Barcode Scanner
  • 1 x Cable
  • 1 x Cradle
  • 1 x Power Supply
  • 1 x Power cord
Ingress Protection (IP) Rating:
  • IP67
  • IP65
Application/Usage:
  • Manufacturing
  • Industrial
  • Component Tracking
  • Inventory
  • Assembly Line
  • Warehouse
  • Logistics
  • Sorting
  • Picking
  • Retail
Environmentally Friendly:
Yes
Environmental Compliance:
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
  • China Restriction of Hazardous Substances (China RoHS)
  • Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211701

Recommended Accessories

Category

  • Batteries (1)
  • Docks and Cradles (4)
  • Mounting Hardware and Stands (1)

Recommended Accessories for Model: Datalogic PM9600-DHP910RBK20 Barcode Scanner

Top Batteries Purchased With Datalogic PM9600-DHP910RBK20

Top Docks and Cradles Purchased With Datalogic PM9600-DHP910RBK20

See All Docks and Cradles for Datalogic PM9600-DHP910RBK20 Barcode Scanner >

Top Mounting Hardware and Stands Purchased With Datalogic PM9600-DHP910RBK20

Frequently Asked Questions

The Standard Range PM9600 features a single camera optimized for conventional reading distances of low-density 1D and 2D codes, while the High Performance variant includes dual cameras for extended reading range and higher resolution capabilities. The High Performance model uses a 1280 x 1024 imager sensor compared to the Standard's 864 x 544 sensor, enabling sharper focus on smaller bar codes at greater distances. Both models are available from us with the same durable construction and Datalogic's signature Green Spot technology.

Yes, the PM9600-DHP910RBK20 operates on a 910 MHz wireless frequency, utilizing Datalogic's proprietary STAR Cordless System technology for reliable cordless operation. This narrow-band radio system eliminates interference from Wi-Fi and Bluetooth environments, making it ideal for warehouse and logistics operations. The kit includes the BC9630-910 cradle and all necessary power components for immediate deployment.

The High Performance PM9600 can read both 1D and 2D barcodes with minimum resolutions of 2.5 mil for 1D codes and 4 mil for 2D codes, providing excellent performance on small or damaged barcodes. It successfully decodes Data Matrix, PDF417, and other 2D symbologies with white LED illumination and Datalogic's 3GL (Three Green Lights) technology for reliable good-read confirmation. The scanner maintains a +/- 40° pitch and yaw reading angle with full 360° roll capability for flexible scanning in any orientation.

The PM9600-DHP910RBK20 RS-232 kit includes the scanner, BC9630-910 cradle, CAB-548 serial cable, 8-0935 power supply, and 6003-0941 power cord for complete out-of-box functionality. RS-232 connectivity makes it compatible with legacy warehouse management systems and point-of-sale platforms that use serial communication protocols. Contact us today if you need to verify compatibility with your specific system infrastructure.

The Document Capture methodology is exclusive to Datalogic and enables the PM9600 to capture full-color photographs of documents, labels, or signatures for quality control and verification purposes. This feature is particularly valuable in logistics and warehouse environments where you need to confirm package contents, capture signatures for delivery proof, or document product condition at receiving. The dual-camera High Performance model excels at this capability while maintaining standard barcode scanning performance.

Yes, the PM9600 series is built to withstand extreme industrial conditions and has been tested for the toughest warehouse and logistics applications, including exposure to dust, moisture, and temperature variations. The scanner features mild white light illumination that performs reliably even on dirty or damaged barcodes, and the removable battery design allows for quick hot-swaps during extended shifts. Visit barcodesinc.com or contact us today to discuss environmental specifications for your specific operational requirements.

The Datalogic PM9600-DHP910RBK20 Barcode Scanner is also known as DTL-PM9600DHP910RBK2 or PM9600DHP910RBK20.
