Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D/ LINEAR CODES:
- Autodiscriminates all standard 1D codes including GS1 DataBar linear codes.
2D CODES:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
STACKED CODES:
- EAN/JAN Composites
- GS1 DataBar Composites;
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Light Source:
LED
Image Sensor Type:
Imager
Depth of Field:
- 2.0 to 6.0 cm / 0.8 to 2.3 in@ 2.5 mils
- 2.0 to 6.0 cm / 0.8 to 2.3 in@ 4 mils Data Matrix
- 2.0 to 20.0 cm / 0.8 to 7.8 in@ 10 mils Data Matrix
- 2.0 to 30.0 cm / 0.8 to 11.8 in@ 10 mils PDF417
- 3.0 to 60.0 cm / 1.1 to 23.6 in@ 13 mils
- 3.0 to 70.0 cm / 1.1 to 27.5 in@ 20 mils
- 3.0 to 110.0 cm / 1.1 to 43.3 in@ 40 mils
Scan Pattern:
- Area
- Omni-directional
Scanner Range:
Standard Range
Scanning Distance:
39.60"
Features:
- Beep
- LCD Display
Display Screen:
Yes
Number of Keys:
16
Cable Type Included:
USB
Stand Included:
Yes
Reading Angle (Skew):
40°
Reading Angle (Pitch):
40°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
- PM9500: Withstands 50 drops from 2.0 m / 6.6 ft onto a concrete surface
Minimum Print Contrast:
15%
Minimum Element Resolution (DataMatrix):
4 mil
Maximum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
1280 x 1024
Illumination Type:
LED
Illumination Color:
White
Air Electrostatic Discharge (+/-):
20kV
