Datalogic PM8500-D910RK10 Barcode Scanner

The Datalogic PM8500-D910RK10 Barcode Scanner has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Datalogic PowerScan PM8500 - Datalogic PowerScan PM8500-D Bar Code Reader - Wireless

Metes out excellent operation and rugged structure with smart retailing features which is an ideal choice for bundling terminals, businesses, supermarkets and grocery stores
Allows productive and precise reading of 1D barcodes
Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
Increases productivity by giving the opportunity to wander, without the tangle of cables

Need a different version? See all Datalogic PowerScan PM8500 Barcode Scanners

Discontinued Need Assistance?

Add to Quote

Datalogic PM8500-D910RK10 Barcode Scanner

Overview

Full specifications (PDF)

Datalogic PowerScan PM8500 Barcode Scanner Model Overview

The Datalogic PowerScan PM8500 cordless area imager offers omnidirectional reading of 1D and 2D codes combined with unlimited mobility guaranteed by the Datalogic STAR Cordless System. The PowerScan PM8500 reader's feature a high-resolution Mega-Pixel imaging sensor that is capable of outstanding performance in industrial applications. It is offered in three optic models: Standard Range and High Density models are for typical bar code reading conditions (for medium and high-resolution codes respectively); the Wide Angle model offers a wider field of view allowing the capture of larger and longer codes.

Datalogic PM8500-D910RK10 Barcode Scanner Overview

The PowerScan PM8500-D is Datalogic Scanning's premium line of rugged industrial handheld data collection products. The PowerScan PM8500 cordless area imager offers omnidirectional reading of 1D and 2D codes combined with unlimited mobility guaranteed by the Datalogic STAR Cordless System.

Detailed Specs

Full specifications (PDF)

Technical Information

Connectivity Technology:

Wireless

Scanning Capability:

Barcode Symbology Supported:

1D / Linear Codes:

Autodiscriminates All Standard 1D Codes Including GS1 DataBar Linear Codes

2D Codes:

Aztec Code
Aztec Mesas
Data Matrix
MaxiCode
QR Code

Postal Codes:

Australian Post
British Post
Canadian Post
China Post
Japanese Post
KIX Post
Korea Post
Planet Code
Postnet
Royal Mail Code (RM4SCC)

Stacked Codes:

EAN/JAN Composites
GS1 DataBar Composites
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
MacroPDF
MicroPDF417
PDF417
UPC A/E Composites

Image Sensor Type:

Imager

Maximum Scan Resolution:

6.60 mil

Depth of Field:

2.9" - 6.1"@5mil
2.1" - 9.7"@10mil
1.9" - 10.6"@13mil
2.1" - 14.4"@20mil
3.1" - 7.3"@5mil - PDF
1.5" - 10"@10mil - PDF
3.1" - 6.5"@7.5mil - Data Matrix
2.7" - 7.7"@10mil - Data Matrix

Scan Pattern:

Omni-directional

Scanning Distance:

11.80"

Network & Communication

Radio Frequency:

Yes

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Physical Characteristics

Form Factor:

Handheld

Height:

8.3"

Width:

2.7"

Depth:

4.5"

Weight (Approximate):

13.80 oz

Miscellaneous

Additional Information:

USB Cable separate

Environmentally Friendly:

Yes

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0778889926437

UPC: 778889926437

EAN: 0778889926437

UNSPSC: 43211701

Reviews

Q&A

Accessories

Service Contracts

Get help from a Barcoding Expert!

The Datalogic PM8500-D910RK10 Barcode Scanner is also known as DTL-PM8500D910RK10 or PM8500D910RK10.
