Datalogic PowerScan PD7100 – Barcode Scanner

Part Number: PD7130-YB-PTRK3

Model: PowerScan PD7100

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Connectivity Technology

Cable

Barcode Symbology Supported

1D / Linear Codes:Auto discriminates all standard 1D codesGS1 DataBar linear codesPostal Codes:China PostStacked CodesGS1 DataBar Expanded StackedGS1 DataBar StackedGS1 DataBar Stacked Omni directional

Light Source

Laser

Image Sensor Type

Imager

Product Description:

Datalogic PowerScan PD7130 Bar Code Reader - Wired - Imager

Explore all Datalogic PowerScan PD7100 Barcode Scanners

Add to Quote

Datalogic PD7130-YB-PTRK3 Barcode Scanner

Overview

Datalogic PowerScan PD7100 Barcode Scanner Model Overview

The Datalogic PowerScan PD7100 is a rugged industrial linear imager that offers the highest standards of reliability, robustness and performance plus exceptional value. The unit is 2-meter drop-tested to concrete, IP65 rated against water and dust, and capable of operating in the most extreme temperature conditions. Three year standard warranty ensures low total cost of ownership. The PowerScan PD7100 features advanced code stitching capabilities, making it easier to read poorly printed and damaged codes the first time. The PowerScan PD7100 is available with two multi-interfaces, depending on application requirements: industrial applications and harsh environments: RS-232, Wedge, Wand Emulation and USB and for POS checkouts: RS-232, IBM 46xx and USB.

Datalogic PD7130-YB-PTRK3 Barcode Scanner Overview

The PowerScan 7100 product series are Datalogic Scanning' s value line of rugged industrial handheld data collection products. The PowerScan D7130 linear imaging corded reader combines rugged durability and extremely snappy reading performance all at an affordable price.

Detailed Specs

Technical Information

Connectivity Technology:

Cable

Barcode Symbology Supported:

1D / Linear Codes:

Auto discriminates all standard 1D codes
GS1 DataBar linear codes

Postal Codes:

China Post
Stacked Codes
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omni directional

Light Source:

Laser

Image Sensor Type:

Imager

Scan Rate:

390 scan/s

Maximum Scan Resolution:

3 mil

Depth of Field:

0.6" - 5.5"@5mil
0" - 17.3"@7.5mil
0" - 23.6"@10mil
0" - 31.5"@13mil
0" - 46.9"@20mil
0.8" - 94.5"@40mil
2" - 118.2"@55mil - Reflective
5.1" - 208.7"@100mil - Reflective

Scan Pattern:

Linear

Interfaces/Ports

Host Interface:

Keyboard Wedge

Physical Characteristics

Form Factor:

Handheld

Product Color:

Black
Yellow

Height:

Width:

Depth:

4.5"

Weight (Approximate):

9.90 oz

Miscellaneous

Additional Information:

USB Cable separate

Environmentally Friendly:

Yes

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 4054318774906

EAN: 4054318774906

UNSPSC: 43211701
