Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes
2D:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
- Dot Code
Postal Codes:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Digital Watermarking:
- Digimarc Barcodes (HP and DC model
Image Sensor Type:
Imager
Scan Mode:
Trigger
Scan Pattern:
Omni-directional
Scanner Range:
Auto Range
Cable Type Included:
Serial
Field of View (Horizontal):
38°
Field of View (Vertical):
24°
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
- Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
- Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °
Minimum Print Contrast:
20%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
100 mil
Direct Part Marking (DPM) Decoding:
Yes
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
Red
