Datalogic PBT7100-BB-PTR Barcode Scanner

The Datalogic PBT7100-BB-PTR Barcode Scanner has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Datalogic PowerScan PBT7100 - Datalogic PowerScan PBT7100 Bar Code Reader - Wireless - Imager
  • Creates a high ROI because of diminishment in workforce and descend inventory errors
  • Scan barcodes with a staggering speed of 390 scan/s
  • Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
  • LED aimer is a perfect choice for patient-facing applications
  • Increases productivity by giving the opportunity to wander, without the tangle of cables
  • Bluetooth technology - Allows compatibility with most of your smart devices
Read More

Need a different version? See all Datalogic PowerScan PBT7100 Barcode Scanners

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner Datalogic PBT7100-BB-PTR Barcode Scanner Datalogic PBT7100-BB-PTR Barcode Scanner Datalogic PBT7100-BB-PTR Barcode Scanner Datalogic PBT7100-BB-PTR Barcode Scanner Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Datalogic PBT7100-BB-PTR Barcode Scanner
Full specifications (PDF)
Datalogic PowerScan PBT7100 Barcode Scanner Model Overview
The Datalogic PowerScan PBT7100 linear imaging barcode reader with Bluetooth wireless technology offers operator freedom from cable entanglement, rugged durability and extremely snappy reading performance all at an affordable price. Datalogic Scanning's innovative and unique optical design of the PowerScan PBT7100 combines features that are normally available on different models into a single device: up to 3 mils maximum code resolution; contact to over 3.0 m / 9.8 ft reading distance on standard paper labels; and wide angle code reading. The result is a versatile, easy to use and intuitive scanner that simplifies any code reading activity.
Datalogic PBT7100-BB-PTR Barcode Scanner Overview

The PowerScan 7100 product series are Datalogic Scanning's value line of rugged industrial handheld data collection products. The PowerScan PBT7100 linear imaging bar code reader with Bluetooth wireless technology offers operator freedom from cable entanglement, rugged durability and extremely snappy reading performance all at an affordable price.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Wireless
Barcode Symbology Supported:

1D / Linear Codes:

  • Autodiscriminates All Standard 1D Codes Including GS1 DataBar Linear Codes

Postal Codes:

  • China Post

Stacked Codes:

  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
Light Source:
LED
Image Sensor Type:
Imager
Scan Rate:
390 scan/s
Maximum Scan Resolution:
3 mil
Depth of Field:
  • 0.6" - 5.5"@5mil
  • 0" - 17.3"@7.5mil
Scan Pattern:
Linear
Scanning Distance:
118.11"
Network & Communication
Bluetooth:
Yes
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Physical Characteristics
Form Factor:
Handheld
Product Color:
Black
Height:
8"
Width:
3"
Depth:
4.5"
Weight (Approximate):
12.50 oz
Miscellaneous
Additional Information:

USB Cable separate

Environmentally Friendly:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 4054318460342
EAN: 4054318460342
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Datalogic PBT7100-BB-PTR Barcode Scanner is also known as DTL-PBT7100-BB-PTR or PBT7100BBPTR.
