Datalogic Magellan 3410VSi Barcode Scanner Model Overview
The Magellan 3410VSi by Datalogic is a state-of-the-art on-counter bar code reader. This high-perfomance scanner boasts a large field of view that enables it to provide outstanding performance on a wide variety of bar codes, including hard-to-read bar codes. The M3410VSi scanner features both high speed sweep and presentation scanning techniques, which ensure maximum productivity and ergonomic ease, even with truncated, out-of-spec or poorly printed codes. The electronics platform of the M3410VSi allows it to get power from a single 5V USB connection, providing excellent performance and easy connection to any point-of-sale system.
The Magellan 3410VSi series of scanners continue the Datalogic tradition of high performance imaging for the point of sale. With the same cables, mounts and exterior plastics as the Magellan 3450VSi, the 3410VSi scanner is easy to integrate into existing installations. The new electronics platform allows the M3410VSi to power from a single 5V USB connection, providing outstanding performance and easy connection to any POS system.
With a large field of view and the capabilities of imaging, the 3410VSi scanners provide outstanding performance on hard-to-read bar codes and seamless reading of a wide variety of bar codes. This Magellan scanner enables both high speed sweep and presentation scanning techniques, ensuring maximum productivity and ergonomic ease, even with truncated (shortened), out-of-spec or poorly printed codes.
ENHANCING THE CUSTOMER EXPERIENCE
The optional Magellan Customer Service Scanner (CSS) enables retailers to easily engage their customers in mobile commerce programs, allowing them to scan bar codes from mobile phone screens or paper coupons while the cashier continues to scan regular items in parallel, resulting in a significant reduction in total transaction time.
ENTERPRISE FEATURES
Remote Management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director and Wavelink Avalanch. Additional capabilities are available with the Value Added Features included in every Magellan scanner.
What barcode types does the Datalogic M3410 scanner read?
The Magellan 3410VSi reads both 1D and 2D barcodes, including all standard linear codes, GS1 DataBar formats, QR codes, Data Matrix, Aztec Code, and stacked codes like PDF417. It also offers optional support for Digimarc digital watermarks and GS1 DW codes, making it versatile for retail and logistics environments. We offer this scanner with full technical support to ensure optimal decoding performance in your operations.
Is the Datalogic M3410VSi compatible with my existing POS system?
Yes, the M3410VSi is designed for easy integration into existing installations and connects via a single 5V USB connection, compatible with any standard POS system. It uses the same cables, mounts, and exterior plastics as the Magellan 3450VSi, so if you're upgrading from that model, installation is straightforward. Contact us today to verify compatibility with your specific POS setup.
What type of connection does this barcode scanner use?
The Datalogic M3410VSi features a USB connection with a 15-inch USB OEM cable and POT cable included. The scanner powers directly from a single 5V USB connection, eliminating the need for a separate power supply and simplifying your checkout or warehouse setup. This makes it ideal for modern POS environments where USB connectivity is standard.
What are the power requirements for the M3410 scanner?
The Magellan 3410VSi accepts DC input from 5-12V and has maximum power consumption of 2.25W at 5V or 3.3W at 12V. Since it powers from a standard 5V USB connection, no external power supply is required, reducing installation complexity and cost. This efficient power design makes it suitable for both countertop and wall-mounted deployments.
What mounting options come with the Datalogic M3410VSi?
The M3410VSi includes both a counter mount and wall mount, allowing flexible installation for presentation-style scanning in retail or warehouse environments. These mounts are compatible with the previous Magellan 3450VSi series, so existing infrastructure can be reused. Visit barcodesinc.com to explore mounting accessories or contact us for custom installation guidance.
How does the M3410VSi compare to previous Magellan models?
The Magellan 3410VSi continues Datalogic's tradition of high-performance imaging while featuring a new electronics platform that powers from a single 5V USB connection—eliminating the need for separate power supplies. It maintains backward compatibility with the same cables, mounts, and exterior plastics as the 3450VSi, making upgrades seamless. Available from us with full technical support to ensure a smooth transition for your existing operations.
The Datalogic M3410-010210-00403 Barcode Scanner is also known as
DTL-M341001021000403
or M341001021000403.
Full specifications (PDF)
