Datalogic Magellan 3300HSi – Barcode Scanner

Part Number: M3301-010110-01104
Model: Magellan 3300HSi
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
1D / Linear Codes:Autodiscriminates all standard 1D codes including GS1 DataBar linear codes2D Codes:Aztec CodeData Matrix (ECC200 Only)MaxiCodeQR CodeStacked Codes:GS1 DataBar CompositesGS1 DataBar Expanded StackedGS1 DataBar StackedGS1 DataBar Stacked OmnidirectionalMicroPDF417PDF417
Light Source
Laser

Product Description:

  Datalogic Magellan 3300HSi In-Counter Bar Code Reader - Cable Connectivity - 4" Scan Distance - 1D, 2D - Laser - Imager - Omni-directional - Serial
Explore all Datalogic Magellan 3300HSi Barcode Scanners
Add to Quote
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner
Datalogic M3301-010110-01104 Barcode Scanner Datalogic M3301-010110-01104 Barcode Scanner Datalogic M3301-010110-01104 Barcode Scanner Datalogic M3301-010110-01104 Barcode Scanner Datalogic M3301-010110-01104 Barcode Scanner Datalogic M3301-010110-01104 Barcode Scanner
Full specifications (PDF)

Datalogic Magellan 3300HSi Barcode Scanner Model Overview

The Datalogic Magellan 3300HSi imager achieves new levels of product reliability by utilizing a solid-state design that does not require the use of laser modules or spinning motors, ensuring years of worry-free operation. Unique features include high performance imaging technology which enables the ability to read both linear and 2D barcodes as well as perform image capture duties. The Magellan 3300HSi also features multiple interfaces in every unit and an RS-232 auxiliary port for attaching a hand-held scanner. A Micro-SD card reader helps with software management, upgrading, and maintenance. Because most of the Magellan 3300HSi scanner features are software based, new capabilities are simple to add, even after the initial installation, increasing the useful life of the scanner and protecting your company's technology investment over time.
Datalogic M3301-010110-01104 Barcode Scanner Overview

The Magellan 3300HSi bar code reader brings Datalogic's new imaging technology to the high-volume point-of-sale. Along with the 3200VSi vertical reader, they are the frst bar code scanners to duplicate the speed and wide feld-of-view of high-performance omnidirectional laser scanners while adding the benefts associated with imaging. This imaging technology provides outstanding performance when capturing hard-to-read bar codes such as truncated (short), out-of-spec, poorly printed and GS1 DataBar codes, and provides support for both linear (1D) and 2D label decoding.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D / Linear Codes:

  • Autodiscriminates all standard 1D codes including GS1 DataBar linear codes

2D Codes:

  • Aztec Code
  • Data Matrix (ECC200 Only)
  • MaxiCode
  • QR Code

Stacked Codes:

  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
  • MicroPDF417
  • PDF417
Light Source:
Laser
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Scan Pattern:
Omni-directional
Scanning Distance:
4"
Interfaces/Ports
Host Interface:
Serial
Physical Characteristics
Form Factor:
In-counter
Height:
6"
Width:
6"
Depth:
3.4"
Weight (Approximate):
1.75 lb
Miscellaneous
Additional Information:

USB Cable separate

Environmentally Friendly:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211701
