Datalogic M3200-010210 Barcode Scanner

The Datalogic M3200-010210 Barcode Scanner has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Datalogic Magellan 3200VSi - Corded Presentation Barcode Scanner, Datalogic Magellan 3200VSi, 2D Imager, Linear/Single Dot, General Purpose, Multi-Interface Connection, SCANNER ONLY, Black/Silver, 5.50in Scan Distance. Includes: Counter/Wall Mount
  • Allows productive and precise reading of 1D barcodes
  • Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
  • Laser scan engine guarantees rapid error free data entry
  • Wired connectivity makes this scanner ideal for retail and desktop applications
Read More
Discontinued Need Assistance?
Add to Quote
Datalogic Magellan 3200VSi Barcode Scanner Model Overview
The Datalogic Magellan 3200VSi barcode reader brings Datalogic's imaging technology to the high-volume point-of-sale. It is the first barcode scanner to duplicate the speed and wide field-of-view of high-performance omnidirectional laser scanners while adding the benefits associated with imaging. This imaging technology provides outstanding performance when capturing hard-to-read barcodes such as truncated (short), out-of-spec, poorly printed and GS1 DataBar codes, and provides support for both linear (1D) and 2D label decoding. The Magellan 3200VSi imager enables both sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease.
Datalogic M3200-010210 Barcode Scanner Overview

The Magellan 3200VSi bar code reader brings Datalogic's new imaging technology to the high-volume point-of-sale. It is the first bar code scanner to duplicate the speed and wide field-of-view of high-performance omnidirectional laser scanners while adding the benefits associated with imaging. This imaging technology provides outstanding performance when capturing hard-to-read bar codes such as truncated (short), out-of-spec, poorly printed and GS1 DataBar codes, and provides support for both linear (1D) and 2D label decoding. The Magellan 3200VSi imager enables both sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D / Linear Codes:

  • Autodiscriminates all standard 1D codes including GS1 DataBar linear codes

2D Codes:

  • Aztec Code
  • Data Matrix
  • ECC200 Only
  • MaxiCode
  • QR Code

Stacked Codes:

  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
  • MicroPDF417
  • PDF417
Light Source:
Laser
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 0.5" - 2.5"@5mil
  • 0.5" - 4.5"@7.5mil
  • 0" - 6.0"@10mil
  • 0" - 8.0"@13mil
  • 0" - 9.0"@20mil
Scan Pattern:
Omni-directional
Scanning Distance:
5.50"
Interfaces/Ports
Host Interface:
Multi-interface
Physical Characteristics
Form Factor:
Desktop
Height:
5.6"
Width:
3.2"
Depth:
6"
Weight (Approximate):
1.30 lb
Miscellaneous
Additional Information:

USB Cable separate

Environmentally Friendly:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 4054318291144, 5712505761359
EAN: 4054318291144, 5712505761359
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Datalogic M3200-010210 Barcode Scanner is also known as DTL-M3200010210 or M3200010210.
