Product Description:

  Fixed Barcode Scanner, Datalogic Gryphon I GFS4550, 2D, MP, Red Illumination, 5-14V, RS232 Only, 2m Cable DB9 Connector, Black
Explore all Datalogic Parts Accessories
Add to Quote
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner

Datalogic Parts Accessory Model Overview

Products and parts from Datalogic.
Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner Overview

EASY INTEGRATION

Designed for easy integration and simple installation, the Gryphon 4500 Fixed Series scan modules provide ready-to-use versatile solutions for kiosks and machine manufacturers. The GFS4500 module can be easily integrated with little effort in different enclosures from multiple sides with its small regular size and various fixing points. The "naked" version GFE4500 is ideal for tailor-made fully integrated solution.

MAXIMUM RELIABILITY

The Gryphon 4500 Fixed Series scan modules are made to last with a durable design for maximum uptime. You can rely on them for both indoor and outdoor applications with the IP54 sealing, the UV protected scratch resistant output window, the wide range operating temperature and the great resistance to accidental drops, shock, and vibrations. RS-232 and USB/RS-232 models have an integrated cable while the USB models are equipped with a locking clip to prevent the USB cable from coming loose or disconnecting.

The 5-year factory warranty proves the Gryphon 4500 Fixed Series has been designed to last.

TOP PERFORMANCE

The Gryphon 4500 Fixed Series 2D scan modules features the most advanced Megapixel sensor technology with distinctive red or white illumination technology with adjustable brightness for outstanding reading performance. The wide angle optics allows snappy scanning of any 1D and 2D barcodes and it starts reading at almost contact while offering improved motion tolerance and first pass decoding of fast-moving codes. The speedy reading of tickets, boarding passes, loyalty cards, and coupons from mobile phone displays is granted by the ultimate decoding algorithms you can count on.

BEST FEEDBACK

Datalogic's 'Green Spot' technology coupled with a high visibility topfront LED and integrated loud beeper with adjustable intensity provide superior good-read feedback.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Light Source:
LED
Image Sensor Type:
Imager
Scanning Distance:
32.30"
Features:
  • Beep
  • Notification LED
  • Vibration
Cable Type Included:
Serial
Field of View (Horizontal):
51°
Field of View (Vertical):
32°
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Reading Angle (Roll):
180°
Motion Tolerance:
70 in/s
Image Formats:
  • TIFF
  • BMP
  • JPEG
Maximum Ambient Light:
120000 lux
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
10 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
15 mil
Minimum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
Red
Interfaces/Ports
Host Interface:
Serial
Power Description
Standby Current:
115 mA
Environmental Conditions
Operating Temperature:
-4°F (-20°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Physical Characteristics
Form Factor:
Fixed Mount
Color Family:
Black
Product Color:
Black
Weight (Approximate):
5.36 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP54
Application/Usage:
  • Retail
  • Ticketing
  • Self Service
  • Healthcare
  • Industrial

Frequently Asked Questions

The Datalogic GFS4550 is a 2D fixed barcode scanner that reads both 1D and 2D barcodes with omnidirectional capability. It features advanced imaging technology with excellent performance on standard, poor, or damaged codes, making it ideal for high-volume warehouse and logistics environments. Contact us today to verify compatibility with your specific barcode formats.

This model features RS232 connectivity via a 2-meter DB9 connector cable and operates on 5-14V power input, making it compatible with most fixed-installation systems. The red illumination technology provides steady, deep red light that is easier on operator eyes compared to flickering alternatives. We offer complete integration support—visit barcodesinc.com or contact us today for installation guidance.

Yes, the GFS4550 is constructed with high-impact resin and features a sealed enclosure that meets industrial standards for water and particulate protection. This design allows it to withstand repeated cleanings with solvents and disinfectant solutions, making it reliable for demanding warehouse, manufacturing, and logistics applications. We offer this scanner as a dependable solution for continuous scanning operations.

The GFS4550's red illumination with 4-Dot aimer technology provides user comfort by delivering steady, deep red light that is easier on the eyes than competitive products with flicker illumination. The highly visible 4-Dot aimer with center cross defines a precise reading zone and reduces accidental reads in multi-barcode environments. Available from us with full technical specifications—contact us today for detailed comparisons.

The Datalogic Gryphon I GFS4550 delivers snappy reading performance with high-speed imaging capabilities optimized for fast-moving codes and continuous scanning operations. It features advanced motion tolerance optics and can read barcodes down to 4 mils, with Datalogic's patented 'Green Spot' technology for good-read visual confirmation. Our team can provide detailed performance specifications—visit barcodesinc.com for complete technical data.

The GFS4550 is designed for easy integration with its simple RS232 connectivity and plug-and-play architecture, making it suitable for system designers and warehouse automation projects. It supports continuous scanning modes and can be triggered remotely using input from programmable logic controllers (PLCs) or external sensors. We offer comprehensive integration support—contact us today to discuss your specific system requirements.

The Datalogic GFS4550-BKK2-RED Fixed Barcode Scanner is also known as DTL-GFS4550BKK2RED or GFS4550BKK2RED.
