Datalogic 944301016 Mobile Computer


0.0

(No reviews)

Be the first to

Write a Review
Datalogic Elf - Wi-Fi (802.11a/b/g), Bluetooth 2.0, Standard Laser Scanner with Green Spot Technology, Windows CE 6.0, 256MB RAM/256MB Flash, 46 key QWERTY Keypad. Interface cables and charging cradle sold separately.
UMTS HSDPA mobile radio for voice and data communication

The Datalogic Elf packs unprecedented features into a compact form factor built for single handed use. Use of an accelerometer eliminates awkward presentation of on screen data and a unique guitar pick stylus provides for intuitive touch screen navigation. Getting a job done quickly has never been easier with a 624 MHz processor and 256 MB RAM. The Elf has a Micro SD card slot supporting SDHC storage cards provides for virtually unlimited storage space for photos taken with the onboard 3MP camera. The Elf features both a 1D laser scanner and 2D barcode imager enable a wide array of barcodes seen across diverse enterprises. Both have Datalogic's patented Green Spot good read technology to improve user efficiency and accuracy HF RFID readers available in combination with barcode readers complete the package. The Elf PDA provides four wireless technologies in the same form factor: Bluetooth EDR for fast data transfer, 802.11a/b/g with Cisco Certified security, UMTS HSDPA for real-time communication outside the enterprise and GPS for location based applications and directions.

Technical Information

  • Scanner Range: Standard Range
  • Connectivity Technology: Wireless
  • Light Source: Laser
  • Electrostatic Discharge (ESD):
    • +/-4 kV DC Contact Discharge
    • +/-8 kV DC Air Discharge
  • Drop Specification: 60" To Concrete
  • Barcode Symbology Supported:
    • 1D:
    • GS1 Databar
    • EAN/UPC
    • Code 39
    • 2/5 Codes
    • Plessey
    • Codabar
    • Code 128
    • EAN128
    • MSI
    • Code 93
    • Code 11

General Information

  • Product Type: Handheld Terminal
  • Brand Name: Datalogic
  • Manufacturer: Datalogic S.p.A
  • Product Model: 944301016
  • Product Name: elf Handheld Terminal
  • Product Line: elf

Physical Characteristics

  • Height: 6.2"
  • Width: 3.2"
  • Depth: 1.7"
  • Weight (Approximate): 14.64 oz

Display & Graphics

  • Display Screen Type: LCD
  • Screen Mode: QVGA
  • Screen Size: 3.5"
  • Display Color: Color
  • Screen Resolution: 640 x 480

Memory

  • Flash Memory: 256 MB
  • Standard Memory: 256 MB
  • Memory Card Slot: Yes
  • Memory Card Supported: microSD High Capacity (microSDHC)

Network & Communication

  • Bluetooth: Yes
  • Wireless LAN: Yes
  • Wireless LAN Standard: IEEE 802.11a/b/g

Processor & Chipset

  • Processor Manufacturer: Marvell
  • Processor Speed: 624 MHz
  • Processor Type: XScale

Battery Information

  • Battery Capacity: 3000 mAh
  • Battery Included: Yes
  • Battery Chemistry: Lithium Ion (Li-Ion)

Software

  • Operating System: Windows CE 6.0

Touchscreen Information

  • Touchscreen: Yes

RFID

  • Maximum Operating Frequency: 13.56 MHz

Keyboard/Keypad

  • Keyboard Layout: QWERTY

Full specifications (PDF)

Full specifications (PDF)

Brand Datalogic
Model Elf
RAM Memory 256 MB
Operating System Windows CE 6.0
Network Connectivity 802.11g, 802.11a, 802.11n, 802.11a/b/g/n, Bluetooth
Style Phone-size
Keypad 46
Scanner Type Laser
Data Collection Type Wireless
Scanner Capability 1D
