Datalogic 943500062 Mobile Computer

The Datalogic 943500062 Mobile Computer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Datalogic Skorpio X5 Pistol Grip - Mobile Computer, Datalogic Skorpio X5, 2D Imager, 28-Key Keypad, Android 10, 3GB RAM/32GB Flash, IP65, Gun, Mid-Range, 4.3in Display, Bluetooth, Contactless, Green Spot, Extended Battery
  • Qualcomm SDA660 System-on-Chip 2.3 GHz platform providing power for the most demanding Apps
  • Android 10 with Google Mobile Services; Android Enterprise Recommended for the ultimate user experience, platform stability and Enterprise features
  • Largest display in its class with a 4.3" WVGA with Gorilla™ hardened glass delivering the highest visibility and readability even in direct sunlight
  • RAM Memory: 3/4 GB; Flash Memory: 32/64 GB
  • Four Scan Engine options: Linear imager, 2D imager Standard Range, 2D imager Mid-Range and 2D near-far Extra Long Range (XLR) with no compromises on data capture capabilities
  • Choice of Wireless charging to eliminate contacts and reduce maintenance costs
  • Rear 13 MP color camera to quickly document proof of damage or condition
  • Removable battery pack with Hot Swap battery technology Standard 3500 mAh or High Capacity 6200 mAh
  • Ruggedized with drop resistance up to 1.8 m / 6 ft to concrete and IP65 sealing to withstand the most harsh and demanding environments
  • -20 to 50 ºC / -4 to 122 ºF operating temperature
  • Dual band MIMO Wi-Fi featuring 802.11ac and 802.11r/k/v for fast roaming
  • 47-key alphanumeric, 38-key function numeric, 28-key numeric to fit specific applications and user needs
  • Bluetooth® v5 to empower Bluetooth peripherals with less power consumption
  • NFC for proximity communications
  • Chemical cleaner's resistant plastics/enclosure to endure frequent cleaning and disinfections
  • Pre-licensed device and browser lockdown powered by 42Gears to prevent device misuse
  • Main market MDM's and TE's compliant
  • EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI. Datalogic Shield, for Android security patches and OS upgrades, is included with EASEOFCARE.
Read More
Discontinued Need Assistance?
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Datalogic Skorpio X5 Mobile Computer Model Overview
The Datalogic Skorpio X5 is a top-of-the-line fully rugged key-based mobile computer. Built to face the toughest enterprise challenges in data capture, the Skorpio X5 stands out in any data collection application from distribution centers to retail stores to healthcare. Skorpio X5 feature a 4.3?? display, the largest in its category, allowing you to run more features-rich applications or have a clearer and more easily readable screen for simpler tasks. Lightweight, ergonomic, and with plenty of different configurations and differentiating features, the Skorpio X5 is the perfect business companion for professionals in the warehouse, shop floor, manufacturing floor, and any logistics facility.
Datalogic 943500062 Mobile Computer Overview

The ultimate Android rugged keyboard mobile computer

SKORPIO X5 IS MORE

Skorpio X5 is the best-in-class fully rugged key-based mobile computer to face the toughest enterprise challenges in Data Capture. The powerful next generation of Datalogic Skorpio family that stands out in any data collection application from distribution centers to retail stores. Lightweight, ergonomic, with plenty of different configurations and differentiating features, Skorpio X5 is the perfect business companion for professionals in the warehouse, shop floor, manufacturing floor and any logistics facility.

MORE POWERFUL AND EXTREMELY RUGGED

Skorpio X5 is powered by the market leader Qualcomm® SDA660 System-onChip platform clocked at 2.3 GHz for top performance in the most demanding applications. It features Google OS Android 10 with GMS and it is validated by Google as an 'Android Enterprise Recommended' (AER) rugged device.

Skorpio X5 is a fully rugged PDT designed for the toughest environments, with an IP65 sealing rating and 1.8 m / 6.0 ft repeated drops to concrete.

TOP READING PERFORMANCE AND SCAN ENGINE OPTIONS

Skorpio X5 features the most comprehensive scan engine choice including a totally new near-far Extra Long Range (XLR) with best in the market snappiness and reading performance even on damaged or covered barcodes.

WIRELESS CHARGING or 'CLASSIC' CONTACTS WIRED CHARGING

With Skorpio X5 you can choose between a full contactless device with state of the art 15 watt Wireless Charging or an industry standard pogo-pin connector version that also allows ethernet connectivity within the Skorpio cradle.

BEST IN CLASS VISIBILITY

Skorpio X5 feature a 4.3'' display, the largest in his category, allowing the user to run more features rich applications or have a clearer and more easily readable screen in simpler apps. The high visibility display perfectly fits also in external environments.

FULL SHIFT CAPACITY

Replaceable battery with Standard 3500mAh or High Capacity 6200mAh choice, hot swappable battery technology and the Datalogic smart Battery Management application, allows customers to run 24/7 operations with no interruptions in the most demanding and scanning intensive applications.

Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
  • 1D
  • 2D
Image Sensor Type:
Imager
Scanner Range:
Medium Range
Google Mobile Services (GMS):
Yes
Wireless Charging:
Yes
Sensor Type:
  • Gyroscope
  • Proximity
  • Accelerometer
  • Ambient Lighting
Features:
  • Gorilla Glass 3
  • Drop Resistant
  • Chemical Resistant
  • Oil Resistant
Drop Specification:

Withstands multiple drops from 1.8 m / 6.0 ft onto steel or concrete according to IEC 60068-2-32 procedure 1. Skorpio X5 XLR with the Rubber Boot applied withstands multiple drops from 2.0 m / 6.6 ft onto steel or concrete according to IEC 60068-2-32 procedure 1.

Illumination Type:
LED
Illumination Color:
White
Depth of Field:
  • 8.0 to 100 cm / 3.1 to 31.4 in (13 mil/EAN)
  • Up to 160 cm / up to 63 in (55 mil/DM)
  • Up to 500 cm / up to 197 in (100 mils Code 39)
  • Up to 400 cm / up to 158 in (160 mils Data Matrix)
Processor & Chipset
Processor Manufacturer:
Qualcomm
Processor Type:
Snapdragon
Processor Model:
SD660
Processor Speed:
2.30 GHz
Memory
Standard Memory:
3 GB
Flash Memory:
32 GB
Memory Card Supported:
SDXC
Display & Graphics
Screen Size:
4.3"
Screen Mode:
WVGA
Screen Resolution:
800 x 480
Display Screen Type:
LCD
Touchscreen Information
Touchscreen:
Yes
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
6
Keyboard/Keypad
Number of Keys:
28
Keyboard Type:
Numeric
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac
Bluetooth:
Yes
Bluetooth Standard:
Bluetooth 5.0
Near Field Communication (NFC):
Yes
Interfaces/Ports
USB:
Yes
USB Type-C:
Yes
Camera
Rear Camera:
Yes
Rear Camera Resolution:
13 Megapixel
Software
Operating System:
Android 10
Power Description
Power Source:
Battery
Battery Information
Battery Capacity:
6200 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Removable Battery:
Yes
Environmental Conditions
Operating Temperature:
-4°F (-20°C) to 122°F (50°C)
Physical Characteristics
Form Factor:
Gun
Rugged:
Yes
Miscellaneous
Package Contents:
  • Skorpio X5 Handheld Terminal
  • Battery
Application/Usage:
  • Logistics
  • Warehouse
  • Retail
  • Manufacturing
  • Healthcare
Ingress Protection (IP) Rating:
IP65
Environmentally Friendly:
Yes
Environmental Certification:
EU RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211715
