Datalogic 901711008 Barcode Scanner

The Datalogic 901711008 Barcode Scanner has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Datalogic Gryphon Desk 2D Plus - D412, 2D Imager with IBM 46XX interface. Color: White. Cables not included, see Accessories.
  • Incredible and responsive 2D scanning even on curved or translucent surfaces
  • Features CMOS image sensor
  • With laser scanning technology you don't have to use any additional lighting as it works effectively in low ambient lighting conditions too
  • Perfect for applications that require direct association with a workstation or a notebook
Read More

Need a different version? See all Datalogic Gryphon Desk 2D Plus Barcode Scanners

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner Datalogic 901711008 Barcode Scanner Datalogic 901711008 Barcode Scanner Datalogic 901711008 Barcode Scanner Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner
Datalogic 901711008 Barcode Scanner
Full specifications (PDF)
Datalogic Gryphon Desk 2D Plus Barcode Scanner Model Overview
With rich feature sets and extensive model options, the Datalogic Gryphon Desk 2D Plus product series from Datalogic Scanning represents the premium level of data collection equipment for general purpose applications. The Gryphon Desk 2D Plus reader series have enhanced optics with improved motion tolerance' allowing codes placed on fast moving objects to be easily and quickly captured, creating the ideal reader for tasks requiring high throughput like those found in retail and light industrial environments.
Datalogic 901711008 Barcode Scanner Overview

The Gryphon D412 Bar Code Reader offer outstanding reading performance in an ergonomic form factor. Extremely versatile and durable these readers are the ultimate solution for applications in retail and light industrial environments where low resolution and/or damaged codes need to be read with consistent and reliable performance.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
2D
Barcode Symbology Supported:

1D / LINEAR CODES

  • Autodiscriminates all standard 1D codes including GS1 Databar linear codes

2D CODES

  • Data Matrix
  • MaxiCode
  • Qr Code

POSTAL CODES

  • Australian Post
  • China Post
  • Japanese Post
  • KIX Post
  • Korea Post
  • Plane Code
  • Postnet
  • Royal Mail Code (rM4SCC)

STACKED CODES

  • Ean/Jan Composites
  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectiona
  • MacroPDF
  • MicroPDF417
  • PDF417
  • UPC A/e Composites
Light Source:
Laser
Image Sensor Type:
CMOS
Maximum Scan Resolution:
6.60 mil
Depth of Field:
  • 1.5cm - 14.0cm@10mil - Data Matrix
  • 0.5cm - 22.0cm@10mil - PD
  • 1.5cm - 22.0cm@13mil - EAN13
Interfaces/Ports
Host Interface:
Multi-interface
Physical Characteristics
Form Factor:
Handheld
Product Color:
White
Height:
7"
Width:
3.2"
Depth:
3.9"
Weight (Approximate):
6.98 oz
Miscellaneous
Additional Information:

Supported Interface:

  • IBM 46XX interface
  • USB interface
  • KBW interface

USB Cable separate

Environmentally Friendly:
Yes
Item Numbers
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Datalogic 901711008 Barcode Scanner is also known as DTL-901711008 or 901711008.
