Wi-Fi Generation:
Wi-Fi 6
CradlePoint MB01-19005GB-GA Wireless Router
Part Number:
MB01-19005GB-GA
Model:
CradlePoint Parts Accessory
CradlePoint Parts Accessory Model Overview
Products and parts from CradlePoint.
CradlePoint MB01-19005GB-GA Wireless Router Overview
Cradlepoint's NetCloud Mobile Performance Service with the R1900 Series router is a ruggedized 5G networking platform, designed to provide persistent connectivity for in-vehicle deployments. Cradlepoint NetCloud provides connectivity, network, security, location, and IoT services to connect everything in the vehicle, while providing access to IT for remote management, troubleshooting, and analytics.
For organizations that depend on field forces and mobile networks, the Cradlepoint R1900 mobile router with the NetCloud Mobile Performance Service plan provides a ruggedized GNSS/GPS-enabled in-vehicle network solution. When coupled with the Advanced Performance Mobile Service plan, it provides threat management, web filtering, application visibility, analytics, and advanced GNSS/GPS functionality including location tracking and cellular coverage maps. The R1900 accommodates environmentally harsh environments while delivering enterprise-class standards of reliability, scalability, comprehensive management, and security.
5G Embedded High-Performance Solution
The R1900 mobile router includes an embedded 5G modem that can automatically switch to Cat 20 LTE if the vehicle moves outside of 5G coverage. In addition, the R1900 is designed to accept the RX30 managed accessories which provide either four additional PoE ports or four additional GbE ports and a second modular modem. It also has the ability to act as a controller for a separate Cradlepoint 5G Wideband Adapter. These two capabilities, along with the continually improved NetCloud platform, ensure the ability for future expansion and the best investment protection available.
Performance
Stateful Firewall Throughput:
940 Mbps
IPS Throughput:
940 Mbps
Application Aware Services & Analytics:
940 Mbps
IPSec VPN Throughput:
400 Mbps
Notable Features
- Deploy the ultimate 5G NR / Cat 20 LTE mobile networking solution with industry-leading features
- Add a second cellular modem with the optional RX30 managed accessory for simultaneous dual-carrier connectivity
- Take advantage of Wi-Fi 6 for the best possible connections
- Enable unified edge security with application aware multi-zone firewalls, IDS/IPS, and internet security
- Define policies through centralized cloud-based management for easy deployment at scale
- Integrate into Automatic Vehicle Location systems with discrete GNSS and dead reckoning
- Create a cellular coverage map for complete visibility into your area's 5G and LTE coverage
- Extend your deployment with additional PoE ports, GPIOs, NetCloud SDK and API, Bluetooth, and container support for customizable solutions
For organizations that depend on field forces and mobile networks, the Cradlepoint R1900 mobile router with the NetCloud Mobile Performance Service plan provides a ruggedized GNSS/GPS-enabled in-vehicle network solution. When coupled with the Advanced Performance Mobile Service plan, it provides threat management, web filtering, application visibility, analytics, and advanced GNSS/GPS functionality including location tracking and cellular coverage maps. The R1900 accommodates environmentally harsh environments while delivering enterprise-class standards of reliability, scalability, comprehensive management, and security.
5G Embedded High-Performance Solution
The R1900 mobile router includes an embedded 5G modem that can automatically switch to Cat 20 LTE if the vehicle moves outside of 5G coverage. In addition, the R1900 is designed to accept the RX30 managed accessories which provide either four additional PoE ports or four additional GbE ports and a second modular modem. It also has the ability to act as a controller for a separate Cradlepoint 5G Wideband Adapter. These two capabilities, along with the continually improved NetCloud platform, ensure the ability for future expansion and the best investment protection available.
Performance
Stateful Firewall Throughput:
940 Mbps
IPS Throughput:
940 Mbps
Application Aware Services & Analytics:
940 Mbps
IPSec VPN Throughput:
400 Mbps
Technical Information
Wireless Specifications
Broadband Transmission Technology:
- Cellular
- Ethernet
Wireless LAN Standard:
IEEE 802.11ax
ISM Band:
Yes
UNII Band:
Yes
ISM Maximum Frequency:
2.40 GHz
UNII Maximum Frequency:
5 GHz
Cellular Generation:
5G
Cellular Data Connectivity Technology:
- LTE Advanced Pro
- UMTS
- HSPA+
Total Wireless Transmission Speed:
221.75 MB/s
Interfaces/Ports
Number of Network (RJ-45) Ports:
4
USB:
Yes
PoE (RJ-45) Port:
Yes
Network & Communication
Ethernet Technology:
Gigabit Ethernet
VPN Supported:
Yes
Multi-SIM Supported:
Yes
Number of SIM Card Supported:
2
SIM Size Supported:
Nano
Physical Characteristics
Form Factor:
Desktop
Height:
1.6"
Width:
6.8"
Depth:
5.8"
Weight (Approximate):
2.16 lb
Item Numbers
GTIN:
0810007805238, 0810007807287
UPC:
810007805238, 810007807287
EAN:
0810007805238, 0810007807287
UNSPSC:
43222609
Frequently Asked Questions
What is included with the CradlePoint MB01-19005GB-GA router?
The CradlePoint MB01-19005GB-GA includes the R1900 router with WiFi 5G modem capability, a 1-year NetCloud Mobile Performance Essentials Plan subscription, and comes without an AC power supply or antennas. This bundle is designed to provide immediate connectivity management for mobile and distributed networks.
What type of internet connections does this CradlePoint router support?
This CradlePoint router supports multiple WAN connection types including mobile broadband via USB or ExpressCard modem with an active plan, as well as Ethernet-based connections such as DSL, Cable, and T1. The device features intelligent routing capabilities to manage traffic across these diverse connection types.
Does the CradlePoint MB01-19005GB-GA offer remote management capabilities?
Yes, the router provides web-based GUI management with both HTTP and HTTPS protocols, including WAN (remote) web-based management access for administrators. It also supports server-based centralized management through WiPipe Central, enabling IT teams to monitor and configure devices from anywhere.
What security features are built into this CradlePoint wireless router?
The router includes comprehensive security features such as MAC address filtering, content filtering, website filtering, VPN support with multiple cipher options (AES, 3DES, DES), and hash algorithms (MD5, SHA128, SHA256, SHA384, SHA512). It supports up to 20 concurrent VPN connections with GRE tunneling and device-to-device VPN capabilities.
What are the operating temperature and environmental specifications?
The CradlePoint MB01-19005GB-GA operates reliably in temperatures from 0 to 40°C (32 to 104°F) with relative humidity between 10% to 85%. The device is rated for storage in temperatures ranging from -20 to 70°C (-4 to 158°F), making it suitable for varied warehouse and logistics environments.
How can I manage performance and prioritize network traffic with this router?
The router features WiPipe™ QoS (Quality of Service) with traffic shaping, SSID-based priority settings, and WAN port speed control capabilities. These performance management tools allow warehouse and logistics operations to prioritize critical traffic and optimize bandwidth allocation across multiple applications and users.
The CradlePoint MB01-19005GB-GA Wireless Router is also known as
MB0119005GBGA
