CP Technologies FCS-1150 Products

Part Number: FCS-1150
Model: Parts
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Image Sensor Type
CMOS
Image Sensor Size
1/3"
White Balance Modes
AWB
Color Supported
ColorMonochrome

Product Description:

  LevelOne H.264 3-Mega Pixel FCS-1150 PoE WDR IP Network Camera w/12x Optical Zoom (Day/Night), TAA Compliant - 3-MP, 12X Optical Zoom, PoE, WDR
Explore all CP Technologies Parts Products
Add to Quote
CP Technologies FCS-1150 Products
CP Technologies FCS-1150 Products
CP Technologies FCS-1150 Products
CP Technologies FCS-1150 Products CP Technologies FCS-1150 Products CP Technologies FCS-1150 Products
Display & Graphics
Image Sensor Type:
CMOS
Image Sensor Size:
1/3"
White Balance Modes:
AWB
Color Supported:
  • Color
  • Monochrome
Field of View:
4.69° to 50.2°
Effective Camera Resolution:
3 Megapixel
Video
Video Formats:
  • MJPEG
  • H.264
Maximum Video Resolution:
2048 x 1536
Maximum Frame Rate:
30 fps
Lens
Lens Type:
Zoom
Minimum Focal Length:
5.20 mm
Maximum Focal Length:
62.40 mm
Lens Included:
Yes
Minimum Aperture:
f/1.8
Maximum Aperture:
f/3
Optical Zoom:
12x
Focus Modes:
Automatic
Exposure
Shortest Shutter Speed:
1/10000 Second
Longest Shutter Speed:
1/5 Second
Network & Communication
Connectivity Technology:
Wired
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Protocols:
  • TCP
  • UDP
  • HTTP
  • HTTPS
  • DHCP
  • PPPoE
  • RTP
  • RTSP
  • IPv6
  • DNS
  • DDNS
  • NTP
  • ICMP
  • ARP
  • IGMP
  • SMTP
  • FTP
  • UPnP
  • SNMP
  • Bonjour
Interfaces/Ports
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Power Description
Maximum Power Consumption:
5.28 W
Physical Characteristics
Mount Type:
  • Wall Mount
  • Ceiling Mount
Height:
2.8"
Width:
3.2"
Depth:
6.9"
Weight (Approximate):
1.40 lb
Miscellaneous
Features:
  • Day/Night
  • SD Card Local Storage
  • 2D Noise Reduction
  • Back Light Compensation (BLC)
Package Contents:
  • Zoom Network Camera, Day & Night, WDR
  • Mounting Kit
  • Screw Kit
  • Quick Installation Guide
  • Resource CD (User Manual, Utility, QIG)
System Requirements:
Operation Systems: Microsoft Windows 8/7/Vista/XP
Certifications & Standards:
  • CE
  • FCC
  • ONVIF
Country of Origin:
Taiwan
Item Numbers
GTIN: 0846359034224
UPC: 846359034224
EAN: 0846359034224
UNSPSC: 46171610
