Code CR5210 – Barcode Scanner – Cable Only

Part Number: CR5210-200-C500
Model: Reader 5000 (CR5000)
to get Free Ground Shipping on your order.
3-year Premium Plus ($54.70)
No, stay at premium support package
$391.85
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
1D: BC412, Codabar, Code 11, Code 32, Code 39, Code 93, Code 128, IATA 2 of 5, Interleaved 2 of 5, GS1 DataBar, Hong Kong 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Pharmacode, Plessey, Straight 2 of 5, Telepen, Trioptic, UPC/EAN/JAN Stacked 1D: Codablock F, Code 49, GS1 Composite (CC-A/CC-B/CC-C), MicroPDF, PDF417 2D: Aztec Code, Data Matrix, Data Matrix Rectangular Extension, Grid Matrix, Han Xin, Maxicode, Micro QR Code, QR Code, QR Model 1 Proprietary 2D: GoCode (Optional License Required)
Image Sensor Type
Imager

Product Description:

  Corded Barcode Scanner, Code CR5210, Retail, Presentation, General Purpose, Driver''s License/2D Area Imager, Dark Gray. Includes: 6 ft Straight USB Cable

Code Reader 5000 (CR5000) Barcode Scanner Model Overview

The Code Reader™ 5000 is an innovative barcode reader designed for fast-paced environments, offering speed and flexibility in data handling. With the capability to read 1D, 2D, and postal barcodes, it seamlessly integrates into any platform, including iOS applications. Featuring a lightweight and ergonomic design, this device ensures efficient operation with options for hands-free or trigger scanning. Plus, its advanced image capture technology allows users to store coupons and signatures without the need for specialized software, enhancing workflow efficiency and significantly improving customer service.

Key Features
  • Hands-free operation or optional trigger reading for large, heavy items
  • Compact, lightweight and ergonomic design for user comfort
  • Customizable driver license data formatting for loyalty and credit applications
  • Optional Age Verification solution for business security
  • Efficient power consumption for extended use
  • Durable design withstands drops and tough environments


Specifications
  • Sensor: CMOS 1.2 Megapixel
  • Dimensions: 5.95" H x 2.80" L x 3.55" W
  • Weight: 11.2 oz (318 g)
  • Operating Temperature: -20° to 55° C / -4° to 131° F
  • Storage Temperature: -30° to 65° C / -22° to 150° F
  • Decode Capability: 1D, Postal Codes, and more
  • Memory Capacity: 128MB Flash ROM, 32MB RAM
  • Communication Interfaces: RS232, USB 2.0, Bluetooth
  • Warranty: 3 years
Code CR5210-200-C500 Barcode Scanner Overview

Unparalleled reading perfomance for your POS and ID scanning workflows.

Barcode reading needs to be extremely easy, especially at the point of sale. A positive consumer experience is paramount to drive repeat business, and one of the drivers of a good buying experience is speed at checkout. The CR5200 aids in checkout speed by providing fast reading of a variety of barcodes on a variety of media, including consumer packaged goods, driver licenses, loyalty cards, receipts, and even dim smartphone screens. All of this speed comes with hands-free operation so cashiers can quickly present items to the scanner with both hands, in any orientation. No need to lose efficiency picking up the reader to point and shoot...the CR5200 can stay on the counter and still facilitate efficiency at point of sale.

Despite all of this power, the CR5200 has a small footprint to leave space for sale items that might lead to last minute purchases and increased revenue for retailers or quick service restaurants. As an added customer engagement tool, the CR5200 can parse driver license data. Easily capture consumer information for credit applications, loyalty registration, or marketing lists without the need for additional hardware.

Small but powerful, the CR5200 delivers leading performance to keep businesses and their consumers happy.

The CR5200 can expedite your workflow and give your team more confidence when it comes to checkout

More for Your Application

  • High-speed, omnidirectional reading of 1D and 2D barcode symbologies
  • Presentation reader with easy hands-free operation and enhanced motion detection
  • User feedback with LED and audible tone
  • Compact footprint with adjustable reading direction
  • Quickly reads barcodes on mobile device screens
  • Data parsing/formatting eases system compatibility
  • Customizable driver license data formatting for loyalty and credit applications
  • Extended read ranges
  • Optional age verification
  • Efficient power consumption
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D:

  • BC412, Codabar, Code 11, Code 32, Code 39, Code 93, Code 128, IATA 2 of 5, Interleaved 2 of 5, GS1 DataBar, Hong Kong 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Pharmacode, Plessey, Straight 2 of 5, Telepen, Trioptic, UPC/EAN/JAN Stacked 1D: Codablock F, Code 49, GS1 Composite (CC-A/CC-B/CC-C), MicroPDF, PDF417

2D:

  • Aztec Code, Data Matrix, Data Matrix Rectangular Extension, Grid Matrix, Han Xin, Maxicode, Micro QR Code, QR Code, QR Model 1 Proprietary

2D:

  • GoCode (Optional License Required)
Image Sensor Type:
Imager
Scan Pattern:
  • Area
  • Omni-directional
Scanner Range:
Extended Range
Scanning Distance:
8.90"
Features:
  • Data Formatter
  • Data Parser
  • Notification LED
Cable Type Included:
USB
Field of View (Horizontal):
51°
Field of View (Vertical):
39°
Image Formats:
  • JPG
  • PGM
Maximum Ambient Light:
96890 lux
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
7.5 mil
Minimum Element Resolution (DataMatrix):
5 mil
Maximum Element Resolution (DataMatrix):
20.8 mil
Minimum Element Resolution (PDF417):
5.8 mil
Maximum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
1280 x 960
Interfaces/Ports
Host Interface:
  • USB
  • Serial
Environmental Conditions
Operating Temperature:
-4°F (-20°C) to 131°F (55°C)
Storage Temperature:
-22°F (-30°C) to 149°F (65°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Hands-free
Color Family:
Gray
Product Color:
Dark Gray
Height:
6"
Width:
3.6"
Depth:
2.8"
Weight (Approximate):
11.22 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP52
Application/Usage:
  • Picking
  • Retail
  • Quick Service Restaurant (QSR)
Platform Supported:
  • Smartphone
  • iOS
Item Numbers
UNSPSC: 43211701
