Citizen CL-S631 Barcode Label Printer Model Overview
The CITIZEN CL-S631 Bar Code/Label Printer is engineered for exceptional performance in desktop environments. With an impressive 300 dpi resolution for sharp text and images, this printer also features a 360-meter ribbon, ensuring minimal downtime and greater productivity. Designed with a unique metal Hi-Lift™ mechanism, it offers easy access for media loading, accommodating various label types, including standard and pediatric medical wristbands. Its powerful 32-bit RISC processor ensures fast throughput, making it ideal for any high-demand workspace.
Key Features
Powerful 32 Bit RISC Processor
300 dpi printing for images or fine text
Thermal transfer or direct thermal printing
Standard & pediatric medical wristband capable
Metal Hi-Lift™ print mechanism
Fully supports 2D barcode applications
Standard serial and USB interfaces
Parallel, Ethernet and wireless LAN networking options
Internal 5-inch (125mm) media capacity
Auto-Sensing ZebraⓇ and DatamaxⓇ emulations available
Specifications
Printing Method: Thermal transfer / direct thermal
Print Width: 4.1" (max)
Resolution: 300 dpi
Print Speed: 4ips TT (6ips DT)
Media Types: Roll or fanfold, Continuous or perforated, Die-cut labels, tags and tickets
Paper Width (min/max): .077" - 4.65"
Paper Thickness: 0.0025" - 0.01"
Paper Roll Size: 5" (max)
Print Length (min/max): .25" - 32"
Ribbon Type: Wax, wax-resin or resin
Ribbon Length: 1182' / 360m
Emulations: Standard: DPLTM and ZPLTM
Barcode Types: Comprehensive support for linear and 2D barcodes
Media Sensing: Transmissive and reflective media sensors
The powerful CL-S631 provides users with unparalleled features in the desktop thermal printer class. With crisp 300 dpi printing for images or fine text and an unprecedented 360-meter ribbon for greater productivity and reduced downtime the CL-s631 is a high-performance printer built for the desktop environment. Citizen's unique metal Hi-Lift mechanism allows easy access for loading of media and/or ribbons and the adjustable media sensor can handle a wide variety of label configurations including standard and pediatric medical wristbands.
The Citizen CL-S631-P-GRY Barcode Label Printer is also known as
CL-S631-P-GRY
IMPORTANT UPDATE: Due to memory chip industry demands, manufacturers are signaling price increases and supply constraints. Contact us now to secure inventory and pricing.IMPORTANT UPDATE: Due to memory chip industry demands, manufacturers are signaling price increases and supply constraints. Contact us now to secure inventory and pricing.
Full specifications (PDF)
