Cisco WS-C3560X-48T-E Data Networking

Cisco Catalyst 3560 Series Switch - Catalyst 3560X 48 Port Data IP Services
  • Effectively increases available bandwidth on your network
  • Features 48 networking ports to meet the requirements of the most demanding workgroups
  • Built-in power supply to ensure all components are being supplied with accurate voltage
  • Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
  • Rack mounting enables you to organize wires & secure cables for professional installation
  • Management capability provides control over setup and configuration of your network
  • Gigabit Ethernet port for ultra-fast network speeds
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
Read More
$11,981.54
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Cisco Catalyst 3560 Series Switch Data Networking Model Overview
The Cisco Catalyst 3560 Series Switch is a line of fixed-configuration, enterprise-class switches that include IEEE 802.3af and Cisco pre-standard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. These are ideal access layer switches for small enterprise LAN access or branch-office environments. Combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection, the Catalyst 3560 Series Switch helps you deploy new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. You can maintain the simplicity of traditional LAN switching and still deploy networkwide intelligent services such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management and high-performance IP routing.
Cisco WS-C3560X-48T-E Data Networking Overview

The Cisco® Catalyst® 3750-X and 3560-X Series Switches are an enterprise-class lines of stackable and standalone switches, respectively. These switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower (available only on the Catalyst 3750-X), IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features. The Cisco Catalyst 3750-X Series with StackWise® Plus technology provides scalability, ease of management and investment protection for the evolving business needs. The Cisco Catalyst 3750-X and 3560-X enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.

Interfaces/Ports
Total Number of Network Ports:
48
Uplink Port:
No
Modular:
No
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
1
Shared SFP Slot:
No
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
Yes
Power Description
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
Rack-mountable
Height:
1.8"
Width:
17.5"
Depth:
18"
Weight (Approximate):
16.10 lb
Miscellaneous
Environmentally Friendly:
Yes
Environmental Certification:
RoHS-5
Warranty
Additional Warranty Information:
  • Product does not ship from original manufacturer
  • Product may not be eligible for original manufacturer warranty, rebates or programs
  • Product condition subject to availability
  • Three years direct replacement warranty provided by Ingram Micro
  • Product ships from IMSourcing facility within 2-3 days or from stock
  • Product May ship in non-standard packaging
  • All returns processed directly from IMSourcing
  • Where applicable, IM indicates an Ingram Micro certified pre-owned product
Item Numbers
GTIN: 5054484877271
EAN: 5054484877271
UNSPSC: 43222612
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Cisco WS-C3560X-48T-E Data Networking is also known as CSC-WSC3560X48TE
