Cisco UCS-C210M2-VCD2 Products

Part Number: UCS-C210M2-VCD2
Model: Accessories
Add to My Shopping List Add to Compare
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
2
Number of Processors Installed
2
Processor Type
Xeon
Processor Model
E5640

Product Description:

  Bare Metal UCS C210M2 Svr.,2xE 2xE5640 CPU,48GB RAM,10x146GB
Explore all Cisco Accessories Accessories
Add to Quote
Cisco UCS-C210M2-VCD2 Products
Cisco UCS-C210M2-VCD2 Products
Processor
Number of Processors Supported:
2
Number of Processors Installed:
2
Processor Type:
Xeon
Processor Model:
E5640
Processor Core:
Quad-core (4 Core)
Processor Speed:
2.66 GHz
Cache:
12 MB
QuickPath Interconnect:
5.86 GT/s
64-bit Processing:
Yes
Hyper-Threading:
Yes
Memory
Standard Memory:
48 GB
Maximum Memory Supported:
192 GB
Memory Technology:
DDR3 SDRAM
Memory Standard:
DDR3-1333/PC3-10600
Total Number of Memory Slots:
12
Storage
Number of Hard Drives:
10
Total Hard Drive Capacity:
3 TB
Hard Drive Interface:
SAS
Hard Drive RPM:
15000
Hard Drive Configuration:
10 x 300GB
Optical Drive Type:
DVD-Writer
Optical Media Supported:
DVD±R/±RW
Controllers
Controller Type:
Serial Attached SCSI (SAS)
RAID Supported:
Yes
RAID Levels:
0, 1, 5, 6, 10, 50, 60
I/O Expansions
Number of Internal 2.5" Bays:
16
Total Number of Expansion Slots:
5
Number of PCI Express x16 Slots:
5
Network & Communication
Ethernet Technology:
  • 10 Gigabit Ethernet
  • Fast Ethernet
Interfaces/Ports
Total Number of USB Ports:
4
Number of USB 2.0 Ports:
4
Network (RJ-45):
Yes
VGA:
Yes
Power Description
Number of Power Supplies Installed:
1
Maximum Power Supply Wattage:
650 W
Physical Characteristics
Form Factor:
Rack
Rack Height:
2U
Height:
3.5"
Width:
17.2"
Depth:
28.4"
Miscellaneous
Package Contents:
  • UCS-C210M2-VCD2 Entry-level Server
  • 6 x HDD Slot Blanking Panel
  • 2 x Short SAS Cables
  • 1 x Rail Kit
Certifications & Standards:

Safety:

  • UL 60950-1 No. 21CFR1040
  • CAN/CSA-C22.2 No. 60950-1
  • IRAM IEC60950-1
  • CB IEC60950-1
  • EN 60950-1
  • IEC 60950-1
  • GOST IEC60950-1
  • SABS/CB IEC6095-1
  • CCC*/CB GB4943-1995
  • CNS14336
  • CB IEC60950-1
  • AS/NZS 60950-1
  • GB4943

EMC: Emissions:

  • 47CFR Part 15 (CFR 47) Class A
  • AS/NZS CISPR22 Class A
  • CISPR2 2 Class A
  • EN55022 Class A
  • ICES003 Class A
  • VCCI Class A
  • EN61000-3-2
  • EN61000-3-3
  • KN22 Class A
  • CNS13438 Class A

EMC: Immunity:

  • EN55024
  • CISPR24
  • KN 61000-4 Series
  • KN 24
Item Numbers
GTIN: 0882658359545
UPC: 882658359545
EAN: 0882658359545
UNSPSC: 43211501
The Cisco UCS-C210M2-VCD2 Products is also known as CSC-UCSC210M2VCD2
