Power Redundant [1050 W] AC 50/60. Auto Ranging (100V to 240V) OR Redundant [1050 W] DC. Max Input N32 A at -40 VDC. DC Input Voltage (Range: -40 to -72 VDC)
Humidity (Relative) Operating: 10% to 90% Storage: 5% to 93%
Altitude Operating: 0 feet to 10,006 feet (0 meters to 3,050 meters) Storage: 0 feet to 39,370 feet (0 meters to 12,000 meters)
Heat Dissipation 1398.67 BTU per hour at 50% workload (estimated)
Temperature Operating: 50° F to 95° F (10° C to 35° C) Storage: -40° F to 149° F (-40° C to 65° C)
Network/NIC CIMC management port: l Not required for Flow Sensor operation. l Used for Out of Band Management Flow Sensor management port: l Users connect to this port to access the WebUI for management. l This interface is also used to communicate to Flow Collectors. Monitoring ports:8 total l Monitoring ports are used to receive SPANned network traffic. l They can be IP Addressed to receive ERSPAN data
