Cisco Nexus 3000 Series Switches overview
The Cisco Nexus®3000 Series Switches are a comprehensive portfolio of 1, 10, and 40 Gigabit Ethernet switches built from a Switch-on-a-Chip (SoC) architecture. Introduced in April 2011, this series of switches provides line-rate Layer 2 and 3 performance and is suitable for Top-of-the-Rack (ToR) architecture. This series of switches has established itself as a leader in High-Frequency Trading (HFT), High-Performance Computing (HPC), and big data environments by pairing high performance and low latency with innovations in performance visibility, automation, and time synchronization.
Cisco Nexus 3500 platform overview
The Cisco Nexus 3500 platform further extends the leadership of the Cisco Nexus 3000 Series by including the innovative Cisco® Algorithm Boost (or Algo Boost) technology. Algo Boost technology, built into the switch Application-Specific Integrated Circuit (ASIC), allows the Cisco Nexus 3500 platform to achieve exceptional Layer 2 and 3 switching latencies of less than 200 nanoseconds (ns). In addition, Algo Boost offers several innovations in latency, forwarding, and performance visibility capabilities:
The Cisco Nexus 3524-XL delivers 24 SFP+ ports with enhanced performance for high-speed data center connectivity. It supports advanced Layer 2 and Layer 3 features including VLAN support with rapid Per-VLAN Spanning Tree Plus (PVRST+), Cisco EtherChannel technology for up to 24 ports per EtherChannel, and jumbo frame support up to 9216 bytes. We offer this switch as part of our comprehensive Cisco networking portfolio for organizations requiring scalable, enterprise-grade connectivity.
Yes, the N3K-C3524P-XL provides comprehensive Layer 3 routing capabilities including support for Static, RIPv2, EIGRP, OSPF, IS-IS, and BGP routing protocols. It also supports VRF-Lite (IP VPN), VRF-aware unicast routing, VRF-aware multicast, and VRF route leaking for advanced network segmentation and multi-tenancy. Available from us with full technical support for complex routing deployments.
The switch includes comprehensive security controls with ingress and egress ACLs supporting standard and extended Layer 3 to 4 filtering for IPv4, ICMP, TCP, and UDP traffic. It offers VLAN-based ACLs (VACLs), port-based ACLs (PACLs), and ACLs on virtual terminals (VTYs) for granular access control. Contact us today for guidance on implementing security policies tailored to your data center requirements.
The Cisco N3K-C3524P-XL supports up to 1024 total Layer 3 interfaces across routed ports, Switch Virtual Interfaces (SVIs), PortChannels, and subinterfaces. It provides 64-way Equal-Cost Multipath (ECMP) routing for load balancing across multiple paths, and supports 4096 ACL entries for advanced traffic management. This makes it ideal for high-availability network architectures in warehouse and logistics environments.
The switch includes multiple redundancy mechanisms such as Spanning Tree Root Guard, Spanning Tree Bridge Assurance, and MSTP (IEEE 802.1s) with 64 instances for flexible network topology protection. It supports HSRP and VRRP for gateway redundancy, and vPC (Virtual Port Channel) technology for active-active link aggregation. Visit barcodesinc.com to explore deployment options for mission-critical logistics and warehouse operations.
Yes, the Nexus 3524-XL is purpose-built for data center and enterprise deployments requiring high-density SFP+ connectivity and advanced switching capabilities. With support for jumbo frames, advanced PortChannel hashing based on Layer 2, 3, and 4 information, and comprehensive VLAN management, it delivers the performance and reliability needed for warehouse management systems and logistics networks. Contact us today for sizing assistance and availability.
