What is the Cisco N9K-C9504-FM and what does it do?
The Cisco N9K-C9504-FM is a Fabric Module designed for the Nexus 9504 chassis, enabling high-performance data center switching and routing. This module provides the fabric connectivity necessary to support line cards and supervisors within the Nexus 9504 system, making it essential for building scalable enterprise networks. We offer this component as part of our comprehensive Cisco networking solutions for warehouse, logistics, and IT infrastructure deployments.
Is the Cisco N9K-C9504-FM compatible with other Nexus chassis models?
The N9K-C9504-FM is specifically designed for the Cisco Nexus 9504 chassis and is not compatible with other Nexus series platforms like the Nexus 7000 or 9300 series. Compatibility is limited to the 9504 platform to ensure proper fabric performance and system stability. Contact us today if you need fabric modules for different Nexus chassis configurations, and our team can recommend the correct components for your network architecture.
What networking features does the Nexus 9504 support with this fabric module?
With the N9K-C9504-FM installed, the Nexus 9504 supports advanced features including Virtual eXtensible LAN (VXLAN), Software-Defined Access (SD-Access), multi-VRF routing, MPLS L3VPN, and programmability via NETCONF, RESTCONF, and gNMI/gNOI. The fabric module enables high-speed packet forwarding and supports Flexible NetFlow for detailed traffic analytics. These capabilities make it ideal for modern data center environments requiring software-defined networking and cloud-ready infrastructure.
What are the software requirements for using the N9K-C9504-FM?
The Cisco Nexus 9504 with this fabric module runs Cisco NX-OS software and supports advanced software features depending on your IOS XE release version. Specific software capabilities may require minimum software versions—for example, certain features require IOS XE 17.8.1 or later. We recommend consulting with our technical team to ensure your software version aligns with your deployment requirements and desired feature set.
Does the Nexus 9504 support out-of-band management with this fabric module?
Yes, the Nexus 9504 platform supports out-of-band device management through RJ45 and USB connectivity options, allowing you to manage the switch independently of production traffic. This is particularly useful in warehouse and logistics environments where reliable network management is critical for AIDC operations. Visit barcodesinc.com to learn more about how we can help you deploy managed switching infrastructure for your facility.
What is the performance capacity of the Nexus 9504 when equipped with fabric modules?
The Nexus 9504 achieves multi-billion packets per second throughput when properly configured with supervisor modules and fabric modules, supporting enterprise-scale data center operations. The exact performance depends on your specific configuration of line cards and supervisors, but the architecture supports very high forwarding rates for both IPv4 and IPv6 traffic. Contact us today to discuss performance specifications for your particular network design and capacity requirements.
