Cisco C9200L-48PXG-4X-1E Switches

Part Number: C9200L-48PXG-4X-1E
Model:
$13,780.31
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
48
Uplink Port
Yes
Modular
Yes
Stack Port
Yes

Product Description:

  Switches, Cisco, Cisco Catalyst C9200L-48PXG-4X Ethernet Switch, 48 Ports, Manageable, Gigabit Ethernet, 10 Gigabit Ethernet, 10/100/1000Base-T, 10GBase-T, 10GBase-X, 3 Layer Supported, Modular, 1000 W Power Consumption, 740 W PoE Budget, Twisted Pair, Optical Fiber, PoE Ports, 1U, Rack-mountable, Lifetime Limited Warranty

Cisco Parts Accessory Model Overview

Products and parts from Cisco.
Cisco C9200L-48PXG-4X-1E Switches Overview

Extend intent-based networking everywhere

Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.

As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.

Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.

With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access.

Interfaces/Ports
Total Number of Network Ports:
48
Uplink Port:
Yes
Modular:
Yes
Stack Port:
Yes
Network (RJ-45):
Yes
Port/Expansion Slot Details:
  • 36 x Gigabit Ethernet PoE+
  • 4 x 10 Gigabit Ethernet Uplink
  • 12 x 10 Gigabit Ethernet PoE+
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology:
  • Gigabit Ethernet
  • 10 Gigabit Ethernet
Network Technology:
  • 10/100/1000Base-T
  • 10GBase-T
  • 10GBase-X
I/O Expansions
Total Number of Expansion Slots:
4
Expansion Slot Type:
Uplink Module
Network & Communication
Layer Supported:
3
Networking Standards:
  • IEEE 802.3at
  • IEEE 802.1s
  • IEEE 802.1w
  • IEEE 802.1p
  • IEEE 802.1x
  • IEEE 802.3ad
  • IEEE 802.3af
  • IEEE 802.1ad
  • IEEE 802.1Q
  • IEEE 802.3u
  • IEEE 802.3
  • IEEE 802.3z
  • IEEE 802.1ae
  • IEEE 802.3bz
  • IEEE 802.3an
Management & Protocols
Manageable:
Yes
Power Description
PoE (RJ-45) Port:
Yes
PoE Budget:
740 W
Input Voltage:
  • 120 V AC
  • 230 V AC
Frequency:
  • 50 Hz
  • 60 Hz
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Number of Power Supplies Supported:
2
Number of Power Supplies Installed:
1
Power Consumption:
1000 W
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
Rack-mountable
Height:
1.7"
Width:
17.5"
Depth:
13.8"
Weight (Approximate):
12.60 lb
Miscellaneous
Package Contents:
  • Catalyst C9200L-48PXG-4X Ethernet Switch
  • 1 x Power Supply
  • AC Power Cord
Application/Usage:
Network
Environmentally Friendly:
Yes
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
Lifetime
Item Numbers
UNSPSC: 43222612
