Full specifications (PDF)
Features:
Fanless
Cisco C9200CX-12T-2X2G-A Ethernet & Network Switches
Part Number:
C9200CX-12T-2X2G-A
Model:
Catalyst 9000
Cisco Catalyst 9200 Ethernet & Network Switches Model Overview
The Cisco Catalyst 9200 Series Switches are designed to simplify intent-based networking across various deployments while delivering enhanced security and performance. These switches extend the power of Cisco's innovative hardware and software, offering exceptional resiliency and operational efficiencies. With full PoE+ capabilities, redundant power supplies, and dynamic power allocation, the Catalyst 9200 ensures reliable operation for your network, making it an ideal choice for growing businesses seeking scalable and secure connectivity solutions.
Key Features:
- Full Power over Ethernet Plus (PoE+) capability for up to 48 ports.
- Resiliency with field-replaceable units (FRUs) and redundant power supplies.
- Stackable architecture with high bandwidth and simple management.
- Enhanced security features like AES MACsec encryption.
- Advanced routing capabilities with Layer 3 support.
Specifications:
- Models: C9200, C9200L, and C9200CX
- Uplink options: Modular and fixed uplinks available
- Power Supply: Various options including 125W, 600W, and 1KW AC
- Dimensions: 1.73 x 17.5 x 13.8 inches
- Weight: Ranges from 4.0 to 12.12 pounds depending on model
- Operating Temperature: -5°C to 45°C at 5000 feet
- Acoustic Noise: Up to 45 dBA depending on load
Cisco C9200CX-12T-2X2G-A Ethernet & Network Switches Overview
Extend intent-based networking everywhere
Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.
As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.
Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.
With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center, or Meraki cloud monitoring.
Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.
As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.
Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.
With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center, or Meraki cloud monitoring.
Technical Information
Interfaces/Ports
Total Number of Network Ports:
12
Uplink Port:
No
Modular:
No
Port/Expansion Slot Details:
- 12 x 1 Gigabit Ethernet Ports
- 2 x 10 Gigabit Ethernet Ports
Media & Performance
Media Type Supported:
- Optical Fiber
- Twisted Pair
Ethernet Technology:
10 Gigabit Ethernet
Network Technology:
- 10Base-T
- 10GBase-X
Network & Communication
Layer Supported:
3
Networking Standards:
- IEEE 802.1s
- IEEE 802.1w
- IEEE 802.1x
- IEEE 802.3ad
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.1D
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3z
- IEEE 802.1ae
- IEEE 802.3bz
- IEEE 802.3an
Management & Protocols
Manageable:
Yes
Power Description
PoE (RJ-45) Port:
Yes
PoE Budget:
80 W
Power Source:
Power Supply
Power Consumption:
80 W
Physical Characteristics
Form Factor:
- Rack-mountable
- Wall Mountable
- Under Table
Height:
1.7"
Width:
6.5"
Depth:
10.6"
Weight (Approximate):
4 lb
Item Numbers
GTIN:
0889728447133
UPC:
889728447133
EAN:
0889728447133
UNSPSC:
43222612
Recommended Accessories
Category
- Cables, Connectors, and Adapters (5)
- Data Networking Device Accessories (1)
- Ethernet & Network Switches (1)
- Ethernet Switch Accessories (1)
- Mounting Hardware and Stands (4)
- Network Switch Modules (3)
- Power Device Accessories (7)
Recommended Accessories for Model: Cisco C9200CX-12T-2X2G-A Ethernet & Network Switches
Top Cables, Connectors, and Adapters Purchased With Cisco C9200CX-12T-2X2G-A
-
Cisco STACK-T4-1M Cables, Connectors, and Adapters1M Type 4 Stacking CableItem on backorder — chat for lead time$426.48 -
Cisco STACK-T4-3M Cables, Connectors, and Adapters3M Type 4 Stacking CableItem on backorder — chat for lead time$363.04 -
Cisco STACK-T4-50CM= Cables, Connectors, and Adapters50CM Type 4 Stacking CableItem on backorder — chat for lead time$213.24
Top Data Networking Device Accessories Purchased With Cisco C9200CX-12T-2X2G-A
-
$1,006.95
Top Ethernet & Network Switches Purchased With Cisco C9200CX-12T-2X2G-A
-
$1,150.47
Top Ethernet Switch Accessories Purchased With Cisco C9200CX-12T-2X2G-A
-
Cisco C9K-CMPCT-PWR-CLP AccessoryPower Systems & Supplies, Cisco, Power Retainer Clip For 9200CX Compact SwitchItem on backorder — chat for lead time$30.31
Top Mounting Hardware and Stands Purchased With Cisco C9200CX-12T-2X2G-A
-
$287.76 -
Cisco RACK-KIT-T1= Mounting Hardware and Stands19, 23, 24 inch and ETSI Type 1 rack mouItem on backorder — chat for lead time$332.50 -
Cisco RACKMNT-19-CMPACT Mounting Hardware and StandsMounting Hardware and Stands, Cisco, 19" Rackmount for 9200CX switchesItem on backorder — chat for lead time$86.93
Top Network Switch Modules Purchased With Cisco C9200CX-12T-2X2G-A
-
Cisco C9200-NM-2Q Network Switch ModulesCatalyst 9200 2 x 40G Network ModuleItem on backorder — chat for lead time$2,210.45 -
Cisco C9200-NM-4G Network Switch ModulesCatalyst 9200 4 x 1G Network ModuleItem on backorder — chat for lead time$440.65 -
Cisco C9200-NM-4X Network Switch ModulesCatalyst 9200 4 x 10G Network ModuleItem on backorder — chat for lead time$1,737.54
Top Power Device Accessories Purchased With Cisco C9200CX-12T-2X2G-A
-
$1,976.08 -
$4,234.48 -
$2,540.69
Frequently Asked Questions
What are the key switching capabilities of the Cisco C9200CX-12T-2X2G-A?
The Cisco Catalyst 9200CX-12T-2X2G-A delivers enterprise-class Layer 2 and Layer 3 switching with 12 ports of 1 Gigabit Ethernet, plus 2 additional 10 Gigabit uplink ports and 2 1 Gigabit ports. It supports full PoE+ capability with an 80W PoE budget, making it ideal for powering IP phones and Wi-Fi 6/6E access points across your network infrastructure.
Does this Cisco switch support cloud management and network automation?
Yes, the C9200CX-12T-2X2G-A integrates seamlessly with Meraki cloud management, providing centralized AI-driven network automation and simplified deployment. This cloud-managed approach eliminates the need for on-premises management infrastructure while delivering intelligent network insights.
What security features does the Cisco Catalyst 9200CX offer?
The Catalyst 9200CX includes advanced security with AES-128 and AES-256 MACsec encryption to protect your network traffic. These enterprise-grade encryption standards ensure data confidentiality and integrity across your switching infrastructure, meeting stringent security compliance requirements.
Can the C9200CX-12T-2X2G-A be stacked with other switches for scalability?
Yes, the Catalyst 9200 Series supports StackWise-160 and StackWise-80 stacking technologies, enabling up to 160 Gbps stacking bandwidth. This allows you to connect multiple switches together for seamless scalability and simplified management as your network grows.
What physical mounting options are available for this switch?
The C9200CX-12T-2X2G-A is designed for flexible deployment with both rack-mountable and wall-mountable options, as well as under-table installation capability. This versatility allows you to integrate the switch into various network environments and facility layouts.
What media types does the Cisco C9200CX-12T-2X2G-A support?
The switch supports both optical fiber and twisted pair (copper) connectivity, providing flexibility in network infrastructure design. This dual-media support allows you to leverage existing cabling investments while enabling high-speed fiber connections for uplinks and long-distance runs. Contact us today to discuss the right configuration for your network needs.
The Cisco C9200CX-12T-2X2G-A Ethernet & Network Switches is also known as
CSC-C9200CX12T2X2GA
