Connectivity Technology:
Wired
Number of Output Devices Supported:
1
Maximum Operating Distance:
9842.52 ft
Bosch Parts Accessory Model Overview
Products and parts from Bosch.
Bosch FVR110M1 Video Hub Overview
The ComNet FVT/FVR110 series is a video transmitter/receiver and data transceiver that supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digitally encoded video and bi-directional data over one multimode or single mode optical fiber. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from all major manufacturers, utilizing time-base correction these units can achieve distances of 48km. The FVT/FVR110 supports Panasonic Proteus™ , Pelco Coaxitron™ and Bosch Bilinx™ Up-the-Coax systems. The FVT110 also transmits a single bi-directional contact closure signal.
Technical Information
Interfaces/Ports
Serial Port:
Yes
Number of ST Ports:
1
Media & Performance
Media Type Supported:
- Coaxial
- Optical Fiber
Physical Characteristics
Form Factor:
Rack-mountable
Item Numbers
GTIN:
0845770008029
UPC:
845770008029
EAN:
0845770008029
UNSPSC:
43201614
Get help from a Barcoding Expert!
The Bosch FVR110M1 Video Hub is also known as
CCN-FVR110M1
