Dimensions:
11.43 cm x 17.62 cm x 2.9 cm (4.5 in x 6.94 in x 1.15 in)
Bosch D8103 Accessory
Part Number:
D8103
Model:
Parts
Bosch Parts Accessory Model Overview
Products and parts from Bosch.
Bosch D8103 Accessory Overview
The B520 Auxiliary Power Supply Module is an auxiliary power supply expansion device that connects to compatible control panels through the SDI2 bus. This module is supervised and communicates all status changes to the control panel.
Industrial, commercial, and institutional facilities are typical installations for the B520 module. The B520 address switches allow for easy device addressing. The SDI2 Out terminals provide auxiliary power for SDI2 expansion devices, such as keypads. The AUX PWR terminals provides added auxiliary power capabilities for additional devices such as PIR motion detectors.
Functions
Supervision monitoring
The module monitors and communicates status information over the SDI2 bus for the following:
Fully charged batteries, connected to the battery terminals, sustain power to the B520 in the event that the AC power fails.
Industrial, commercial, and institutional facilities are typical installations for the B520 module. The B520 address switches allow for easy device addressing. The SDI2 Out terminals provide auxiliary power for SDI2 expansion devices, such as keypads. The AUX PWR terminals provides added auxiliary power capabilities for additional devices such as PIR motion detectors.
Functions
Supervision monitoring
The module monitors and communicates status information over the SDI2 bus for the following:
- Operation (Heartbeat)
- Battery 1 (BATT 1)
- Battery 2 (BATT 2)
- AC input power (AC)
- Battery OK
- Low Battery
- Missing Battery
- Heartbeat [icon]. Blue LED flashing On and Off when system is operating normally. A steady On or Off LED indicates a system fault. Triple flash indicates communication failure.
- BATT 1 LED. Green steady On LED indicates the battery status of BATT 1 is operating normally. Flashing indicates low battery. Triple flash indicates battery charger failure. Off LED indicates a missing battery.
- BATT 2 LED. Green steady On LED indicates the battery status of BATT 2 is operating normally. Flashing indicates low battery. Triple flash indicates battery charger failure. Off LED indicates a missing battery.
- AC LED. Green steady On LED indicates the AC power is operational. A pulsating LED (3 pulses per second) occurs when a battery test is being performed. Flashing indicates low or failed AC.
Fully charged batteries, connected to the battery terminals, sustain power to the B520 in the event that the AC power fails.
Physical Characteristics
Miscellaneous
Compatibility:
Control panels:
- B9512G/B9512G-E (Up to 8 modules)
- B8512G/B8512G-E (Up to 4 modules)
- B6512 (Up to 4 modules)
- B5512/B5512E (Up to 4 modules)
- B4512/B4512E (Up to 2 modules)
- B3512 (Up to 2 modules)
- D9412GV4 v 2.xx (Up to 8 modules)
- D7412GV4 v2.xx (Up to 8 modules)
- B8103 Universal Enclosure and D8103 Universal Enclosure (holds up to two 18 Ah, or two 7 Ah batteries)
- B10 Medium Control Panel Enclosure (Holds up to one 18 Ah, or two 7 Ah batteries)
- B12 Mounting Plate for the D8103 Enclosure
- D8108A Attack Resistant Enclosure
- D2203 Enclosure
- BATB-40 Enclosure
- AE1/AE2 Enclosures
- D8004 Transformer Enclosure
- TR1850 (18 VAC, 50 VA)
- TR1850-CA (18 VAC, 50 VA) for Canada
Item Numbers
GTIN:
0800549723268
UPC:
800549723268
EAN:
0800549723268
UNSPSC:
39121000
Get help from a Barcoding Expert!
The Bosch D8103 Accessory is also known as
BOS-D8103
