Device Supported:
Control Panel
Bosch B942 Security Camera
Part Number:
B942
Model:
Parts
Bosch Accessory Model Overview
Products and parts from Bosch.
Bosch B942 Security Camera Overview
- Color graphic touch screen display uses a combination of simple icons and text for easy operation
- Built-in presence detector lights the display when user approaches keypad
- Built-in proximity reader allows use of a token or card as replacement for a passcode, or for use with dual authentication for high security areas
- Four inputs and one output provide cost effective expansion
- Slim, modern design blends with any decor
Technical Information
Physical Characteristics
Color Family:
White
Product Color:
White
Product Material:
- ABS Plastic
- Acrylic
Height:
4.7"
Width:
6.2"
Depth:
0.7"
Weight (Approximate):
11.30 oz
Miscellaneous
Additional Information:
- Display window Touch screen Multi-line messages
- Indicators Power indicator LED Status indicators Main icon Warning and indicating tones
- Inputs 4 (four) 1k Ω supervised inputs
- Output 1 (one) NO (normally open) contact
- Relative humidity 5% to 93% at +32°C (+90°F) non-condensing
- Temperature (operating) 0°C to +50°C (+32°F to +122°F)
- Current with proximity reader disabled Standby: 200 mA Alarm: 300 mA
- Current with proximity reader enabled Standby: 300 mA Alarm: 400 mA
- Voltage (input) 12 VDC nominal
Application/Usage:
- Commercial
- Home
- Residential
Compatibility:
Intrusion Alarm Systems
Item Numbers
UNSPSC:
46171600
The Bosch B942 Security Camera is also known as
BOS-B942
