Device Supported:
Control Panel
Bosch B921C Security Camera
Part Number:
B921C
Model:
Parts
Bosch Accessory Model Overview
Products and parts from Bosch.
Bosch B921C Security Camera Overview
The B921C keypad is an SDI2 bus compatible device. The keypad features capacitive touch keys, instead of the mechanical buttons found on most keypads. With a smooth, sleek surface, the keypad is easy to clean, and fits with any modern decor. The keypad has user adjustable options such as volume and brightness. The keypad has three programmable emergency keys, and four inputs. The keypad also shows two-line system messages for all areas.
Technical Information
Power Description
Input Voltage:
12 V DC
Environmental Conditions
Minimum Operating Temperature:
32°F (0°C)
Maximum Operating Temperature:
122°F (50°C)
Physical Characteristics
Product Color:
Black
Product Material:
- ABS Plastic
- Polymethyl Methacrylate (PMMA)
Height:
4.7"
Depth:
1"
Width:
6.2"
Weight (Approximate):
11.30 oz
Miscellaneous
Package Contents:
- B921C Capacitive Keypad with Inputs (SDI2)
- 1 x Hardware Pack
- 4 x 1k Ω EOL Resistors
- 1 x Installation Guide
Additional Information:
- 2-line LCD display with up to 32 character point, user, and area names
- Capacitive touch keys clean easily and are more resistant to wear than traditional mechanical buttons
- Situation sensitive on-screen help makes system operation simple and easy
- Highly visible on (arm)/alarm, ready to turn on (arm), power, trouble, and gas alarm indicators
- Four inputs provide simple, lower-cost point expansion
Compatibility:
Bosch Control Panels:
- B9512G
- B9512G-E
- B8512G
- B8512G-E
- B5512
- B5512E firmware v2.02 and higher
- B4512
- B4512E firmware v2.02 and higher
- B3512
- B3512E firmware v2.02 and higher
- D9412GV4
- D7412GV4 firmware v2.02 and higher
Certifications & Standards:
- UL
- CSFM
Item Numbers
GTIN:
0065805942542, 0800549728959
UPC:
065805942542, 800549728959
EAN:
0065805942542, 0800549728959
UNSPSC:
46171600
Get help from a Barcoding Expert!
The Bosch B921C Security Camera is also known as
BOS-B921C
