Number of Events Log:
127
User Code Storage:
33
Bosch B4512-C Security Camera
Part Number:
B4512-C
Model:
Parts
Bosch Parts Accessory Model Overview
Products and parts from Bosch.
Bosch B4512-C Security Camera Overview
- Supports up to 28 points using a combination of hardwired or wireless points for installation flexibility and 2 areas with perimeter and interior control
- On-board Ethernet port for Conettix IP alarm communication and remote programming, compatible with modern IP networks including IPv6/IPv4, Auto-IP and Universal Plug and Play
- Installer-friendly features including on-board USB for easy on-site RPS programming, plus plug-in PSTN and Cellular co
With the B4512, you can monitor doors, windows, and motion within areas like showrooms or those that hold inventory. Each user can have a personalized passcode, a wireless keyfob, and a credential to control the system.
Technical Information
Network & Communication
Sensor Connectivity:
- Hardwired
- Wireless
Ethernet:
Yes
Power Description
Input Voltage:
12 V DC
Miscellaneous
Package Contents:
- B4512 Fire Alarm Control Panel
- 1 x Literature Pack
- UL Installation Instructions
- Owner's Manual
- Release Notes
- SIA Quick Reference Guide
- 1 x Literature CD Containing Product Literature
Additional Information:
- Relative humidity 5% to 93% at +90? (+32?), non-condensing
- Temperature (operating) +32°F to +122°F (0°C to +49°C)
- Areas 2
- Custom functions 2
- Events Up to 127
- Passcode users 32, plus 1 Installer passcode
- Points 28 (8 on-board, up to 20 off-board)
- Programmable outputs 27 (3 on-board, up to 24 off-board)
- RF points 20
- SKEDs 5
- Current draw (maximum) Idle 125 mA; Alarm 155 mA
- Output (alarm) 1.3 A at 12 VDC
- Output (auxiliary, continuous power, and switched auxiliary combined): 800 mA at 12 VDC nominal
- 28-Point IP Alarm Control Panel Kit, 5-Piece with B4512, B10, CX4010, B444-V, B920
Certifications & Standards:
- UL
- ULC
- CSFM
Environmentally Friendly:
Yes
Item Numbers
UNSPSC:
46182504
Get help from a Barcoding Expert!
The Bosch B4512-C Security Camera is also known as
BOS-B4512C
