Bogen ASUG1DK Public Address Equipment

Bogen Model AS-1 is an advanced eight-inch cone-type amplified loudspeaker designed for superior telephone paging applications. Featuring a built-in amplifier with an adjustable volume control, the AS-1 delivers excellent sound quality without the need for a centralized amplifier system. Compact and easy to install using standard telephone station wire, this loudspeaker is perfect for small setups where clear communication is essential. With the option to drive multiple units from a single power supply, the AS-1 is an efficient solution for both paging and background music integration.

Key Features:

• Ideal for telephone-paging systems
• Self-contained amplifier for cost-efficient small systems
• Easy installation using standard telephone station wire
• Built-in volume control for straightforward operation

Specifications:

• Rated Output: 1 watt
• Frequency Response: 10Hz to 10kHz
• Distortion at Rated Output: 1.5% max.
• Signal to Noise Ratio: -70dB
• Input Impedance: 1000 ohms
• Input Sensitivity: 113mV ±4dB
• Sound Pressure Level: 92dB @ four feet on axis with 1 watt input at 1000Hz
• Dispersion: 90°
• Size: 8" cone
• Volume Control: Outgoing level adjust
• Supply Voltage Range: 24VDC ±10%
• Nominal Operating Current: 50mA
• Idle Current: 20mA
• Shipping Weight: 2 lbs. (.91 kg)
