Black Box LBH120A-H-ST Wireless Switch

Part Number: LBH120A-H-ST
Model: Parts

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
5
Token Ring Port
No
LRE Port
No
Bypass
No

Product Description:

  Black Box LBH 120 Ethernet Switch - 5 Ports - TAA Compliant - 2 Layer Supported - Twisted Pair, Optical Fiber - Rail-mountable, DIN Rail Mountable - 5 Year Limited Warranty
Interfaces/Ports
Total Number of Network Ports:
5
Token Ring Port:
No
LRE Port:
No
Bypass:
No
Management Port:
No
USB:
No
Number of Network (RJ-45) Ports:
4
Number of ST Ports:
1
ST Port Type:
Duplex
Port/Expansion Slot Details:
5 x Fast Ethernet Network
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Fiber Mode Supported:
Multi-mode
Ethernet Technology:
Fast Ethernet
Network Technology:
  • 10/100Base-TX
  • 100Base-X
Network & Communication
Layer Supported:
2
Power Description
Power Source:
Power Supply
Physical Characteristics
Form Factor:
  • Rail-mountable
  • DIN Rail Mountable
Height:
4.3"
Width:
1"
Depth:
2.8"
Weight (Approximate):
8 oz
Miscellaneous
Package Contents:
  • LBH 120 Ethernet Switch
  • Din Rail Mounting Kit
Certifications & Standards:
EMI:
  • FCC Part 15, Class A
  • EN61000-6-3: EN55022
  • EN61000-3-2
  • EN61000-3-3
EMS:
  • EN61000-6-2:EN61000-4-2
  • EN61000-4-3
  • EN61000-4-4
  • EN61000-4-5
  • EN61000-4-6
  • EN61000-4-8
  • EN61000-4-11
Environmental test:
  • IEC60068-2-6 Fc
  • IEC60068-2-27 Ea
  • IEC60068-2-32 Ed 0
  • IP30
  • CE
  • TAA
IEEE Standards:
  • 802.3x
  • 802.3
  • 802.3u
Environmentally Friendly:
Yes
Environmental Certification:
  • WEEE
  • RoHS
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0700604246384, 0700736532713, 0822088105237
UPC: 700604246384, 700736532713, 822088105237
EAN: 0700604246384, 0700736532713, 0822088105237
UNSPSC: 43222612
