Network (RJ-45):
Yes
Black Box LB200A-R4 Wireless Switch
Part Number:
LB200A-R4
Model:
Parts
Interfaces/Ports
Physical Characteristics
Height:
1.5"
Width:
4.1"
Depth:
3.8"
Miscellaneous
Package Contents:
- Ethernet Extender - Unmanaged, 2-Port
- 1 x Remote Unit
- 1 x Local Unit
- 2 x Power Supplies with (2) Power Clips (U.S. and EU)
Additional Information:
Connectors
Line: (1) RJ-45;
Ethernet: (2) RJ-45 10/100BASE-T
Power: (1) IEC-320
Indicators (6) LEDs: (1) Power, (1) Line, (1) Local, (1) Remote, (1) Eth 0, (1) Eth 1
Interface Ethernet: 10BASE-T/100BASE-TX
Operation Ethernet: 10/100 full- or half-duplex, auto-negotiating
Power Input: Via external 120-240 VAC, 50-60 Hz, universal, autosensing power supply;
Output: 1 A at 5 VDC
Speed
Long-range asymmetrical mode:
67 Mbps downstream and 16 Mbps upstream at up to 250 ft. (76 m);
59 Mbps downstream and 16 Mbps upstream at up to 1000 ft. (305 m);
45 Mbps downstream and 11 Mbps upstream at up to 2000 ft. (610 m);
31 Mbps downstream and 16 Mbps upstream at up to 3000 ft. (914 m);
17 Mbps downstream and 682 kbps upstream at up to 5000 ft. (1.5 km);
4 Mbps downstream and 263 kbps upstream at up to 10,000 ft. (3 km)
High-speed asymmetrical mode:
168 Mbps downstream and 95 Mbps upstream at 250 ft. (76 m);
126 Mbps downstream and 54 Mbps upstream at 1000 ft. (305 m);
60 Mbps downstream and 21 Mbps upstream at 2000 ft. (610 m);
42 Mbps downstream and 6 Mbps upstream at 3000 ft. (914 m);
35 Mbps downstream and 1 Mbps upstream at 3500 ft. (1 km)
High-speed symmetrical mode:
121 Mbps downstream and 144 Mbps upstream speeds at distances up to 250 feet (76 m);
73 Mbps downstream and 103 Mbps upstream speeds at distances up to 1000 feet (305 m);
45 Mbps downstream and 37 Mbps upstream speeds at distances up to 2000 feet (610 m);
30 Mbps downstream and 10 Mbps upstream speeds at distances up to 3000 feet (914 m);
16 Mbps downstream and 4 Mbps upstream speeds at distances up to 3500 feet (1 km)
Line: (1) RJ-45;
Ethernet: (2) RJ-45 10/100BASE-T
Power: (1) IEC-320
Indicators (6) LEDs: (1) Power, (1) Line, (1) Local, (1) Remote, (1) Eth 0, (1) Eth 1
Interface Ethernet: 10BASE-T/100BASE-TX
Operation Ethernet: 10/100 full- or half-duplex, auto-negotiating
Power Input: Via external 120-240 VAC, 50-60 Hz, universal, autosensing power supply;
Output: 1 A at 5 VDC
Speed
Long-range asymmetrical mode:
67 Mbps downstream and 16 Mbps upstream at up to 250 ft. (76 m);
59 Mbps downstream and 16 Mbps upstream at up to 1000 ft. (305 m);
45 Mbps downstream and 11 Mbps upstream at up to 2000 ft. (610 m);
31 Mbps downstream and 16 Mbps upstream at up to 3000 ft. (914 m);
17 Mbps downstream and 682 kbps upstream at up to 5000 ft. (1.5 km);
4 Mbps downstream and 263 kbps upstream at up to 10,000 ft. (3 km)
High-speed asymmetrical mode:
168 Mbps downstream and 95 Mbps upstream at 250 ft. (76 m);
126 Mbps downstream and 54 Mbps upstream at 1000 ft. (305 m);
60 Mbps downstream and 21 Mbps upstream at 2000 ft. (610 m);
42 Mbps downstream and 6 Mbps upstream at 3000 ft. (914 m);
35 Mbps downstream and 1 Mbps upstream at 3500 ft. (1 km)
High-speed symmetrical mode:
121 Mbps downstream and 144 Mbps upstream speeds at distances up to 250 feet (76 m);
73 Mbps downstream and 103 Mbps upstream speeds at distances up to 1000 feet (305 m);
45 Mbps downstream and 37 Mbps upstream speeds at distances up to 2000 feet (610 m);
30 Mbps downstream and 10 Mbps upstream speeds at distances up to 3000 feet (914 m);
16 Mbps downstream and 4 Mbps upstream speeds at distances up to 3500 feet (1 km)
Environmentally Friendly:
Yes
Environmental Certification:
- WEEE
- RoHS
Country of Origin:
United States
TAA Compliant:
Yes
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN:
0088442852739, 0655093174208, 0818287053394, 0822088077312
UPC:
088442852739, 655093174208, 818287053394, 822088077312
EAN:
0088442852739, 0655093174208, 0818287053394, 0822088077312
UNSPSC:
43222608
