Black Box KVXHP-400 Network Switch

Black Box - Black Box Corporatio Black Box KVXHP-400 KVM Extender, 2 Computer(s), 2 Local User(s), 13123.36 ft Range, 4K, 2 x Network (RJ-45), 6 x USB, DisplayPort, 12 V DC Input Voltage, Rack-mountable, 1U, TAA Compliant

Quad-Head video at HD60 via DisplayPort 1.2 MST (Multi-Stream Technology)
Point to point extension up to 328 ft (100m) over CATx or 2.5 miles (4km) over fiber cable
CATx or Fiber flexibility
True USB emulation supports the most advanced keyboards and mice
Intelligent EDID management reduces monitor compatibility issues
Digital / Analog audio
4 x Tri-color connection status LEDs
Single or Dual-Head models also available

Need a different version? See all Black Box Parts Products

$2,457.28

Chat Now for Qty Discount

Add to Quote

Detailed Specs

Technical Information

Connectivity Technology:

Wired

Number of Computers Supported:

Number of Local Users Supported:

Maximum Operating Distance:

13123.36 ft

Device Type:

KVM Extender

Video

Graphic Mode:

Interfaces/Ports

Network (RJ-45):

Yes

USB:

Yes

Headphone:

Yes

Microphone:

Yes

DisplayPort:

Yes

Number of Network (RJ-45) Ports:

Number of USB Ports:

Power Description

Input Voltage:

12 V DC

Physical Characteristics

Rack Height:

Form Factor:

Rack-mountable

Transmitter Height:

1.54"

Transmitter Width:

7.32"

Transmitter Depth:

5.83"

Receiver Height:

1.54"

Receiver Width:

7.32"

Receiver Depth:

5.83"

Transmitter Weight (Approximate):

2.84 lb

Receiver Weight (Approximate):

2.73 lb

Miscellaneous

Package Contents:

1 x Transmitter
1 x Receiver
2 x 12V, 1.5A Power Supply
1 x DisplayPort cables M/M, 1.8m (6 ft.)
1 x USB Type A to B cables, M/M, 1.8m (6 ft.)
1 x 3.5mm audio cable, MM, 3m (10 ft.)
2 x US Power Cords

Environmentally Friendly:

Yes

Environmental Certification:

WEEE
RoHS

Country of Origin:

United Kingdom

TAA Compliant:

Yes

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0822088151890

UPC: 822088151890

EAN: 0822088151890

UNSPSC: 43211603
