Distance Between local and remote units in a direct CATx application and between network switches: 328 ft. (100 m)* maximum
Network Operation When used to extend over an Ethernet IP network: Data traffic: Layer 2; Management traffic: Layer 3 (dynamic or static IP assignments)
Operating Humidity 20 to 80%, noncondensing
Operating Temperature 32 to 122° F (0 to 50°C)
Power Input From 100-240 VAC, 50-60 Hz adapter (included)
Power Output 24 VDC
RoHS Yes
Speeds Up to 480 Mbps*
Standards FCC (Class B), IC (Class B), CE (Class B); ESD Rating: EMC EN-61000-4-2:2001 8kV Contact, 16kV Air
Storage Humidity 10 to 90%, noncondensing
Connectors Local unit: USB: (1) USB Type B F; Interconnect: (1) RJ-45; Remote unit: USB: (4) USB Type A F; Interconnect: (1) RJ-45
Dimensions 1"H x 3.9"W x 3"D (2.6 x 10 x 7.6 cm)
Indicators On each unit: (4) LEDs (Power, Link, Host, Activity)
Weight 3.1 lb (1.4 kg)
Certifications & Standards:
CE
Country of Origin:
China
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
The Black Box IC408A-R2 Wireless Switch is also known as
BLB-IC408AR2
